Samsung ST55W3PCX/XAX Service Manual page 65

Electrical Parts List
Loc. No. Code No. Description ; Specification
6 R658 2001-000812 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2mm
6 R672 2001-000812 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2mm
6 R687 2001-000812 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2mm
6 R685 2001-001000 R-CARBON ;82Kohm,5%,1/8W,AA,TP,1.8x3.2mm
6 R811 2001-001071 R-CARBON(S);12KOHM,5%,1/2W,AA,
6 R801 2001-001077 R-CARBON(S);150OHM,5%,1/2W,AA,
6 R674 2001-001103 R-CARBON(S);20KOHM,5%,1/2W,AA,TP,2.4X6.4
6 R677 2001-001103 R-CARBON(S);20KOHM,5%,1/2W,AA,TP,2.4X6.4
6 R681 2001-001146 R-CARBON(S);4.7OHM,5%,1/2W,AA,
6 R682 2001-001146 R-CARBON(S);4.7OHM,5%,1/2W,AA,
6 R814 2003-001098 R-METAL OXIDE(S);22KOHM,5%,3W,AA,TP,6X16
6 R805 2004-000970 R-METAL;470ohm,1%,1/4W,AA,TP,2.4x6.4mm
6 R675 2004-001390 R-METAL(S);1KOHM,2%,1/2W,AA,TP
6 R676 2004-001390 R-METAL(S);1KOHM,2%,1/2W,AA,TP
6 R673 2004-001970 R-METAL(S);1.8KOHM,1%,1/2W,AA,
6 R678 2004-001970 R-METAL(S);1.8KOHM,1%,1/2W,AA,
6 R679 2004-001970 R-METAL(S);1.8KOHM,1%,1/2W,AA,
6 R680 2004-001970 R-METAL(S);1.8KOHM,1%,1/2W,AA,
6 C694 2301-000192 C-FILM,PEF;1NF,5%,50V,5.3X10MM
6 C695 2301-000192 C-FILM,PEF;1NF,5%,50V,5.3X10MM
6 C682 2305-000665 C-FILM;104J, 60V,5MM TAPING
6 C687 2305-000665 C-FILM;104J, 60V,5MM TAPING
6 C689 2305-000665 C-FILM;104J, 60V,5MM TAPING
6 C716 2401-000025 C-ALUMINUM;100uF,20%,16V,GP,TP.6.3x11,5
6 C803 2401-000025 C-ALUMINUM;100uF,20%,16V,GP,TP.6.3x11,5
6 C819 2401-000025 C-ALUMINUM;100uF,20%,16V,GP,TP.6.3x11,5
6 C822 2401-000025 C-ALUMINUM;100uF,20%,16V,GP,TP.6.3x11,5
6 C104 2401-000039 C-ALUMINUM;1000UF,20%,16V,GP,10*16MM,EA
6 C832 2401-000039 C-ALUMINUM;1000UF,20%,16V,GP,10*16MM,EA
6 C686 2401-000192 C-ELEC;CE04-40/8550VT102-MW1SG
6 C688 2401-000192 C-ELEC;CE04-40/8550VT102-MW1SG
6 C102 2401-000302 C-AL;100UF,20%,25V,GP,6X11MM,5
6 C610 2401-000302 C-AL;100UF,20%,25V,GP,6X11MM,5
6 C620 2401-000360 C-AL;100UF,20%,50V,GP,8X11MM,5
6 C806 2401-000360 C-AL;100UF,20%,50V,GP,8X11MM,5
6 C802 2401-000471 C-AL;10UF,20%,50V,BP,6X11MM,5M
6 C147 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C601 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C604 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C631 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C632 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C633 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C652 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C656 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C664 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C668 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C669 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C670 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C674 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C675 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C676 2401-000480 C-AL;10UF,20%,50V,GP,5X11MM,5M
6 C108 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM
6 C113 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM
6 C679 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM
6 C680 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM
6 C684 2401-000603 C-AL;1UF,20%,50V,GP,5X11MM,5MM
6 C827 2401-000832 C-AL;220UF,20%,25V,GP,8X11MM,5
6 C124 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C125 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C134 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C135 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C136 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C137 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C138 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C139 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C607 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C609 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C612 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C617 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C629 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C630 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C639 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C640 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C683 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
6 C685 2401-001192 C-AL;33UF,20%,50V,GP,6X11MM,5MM,TP
6 C830 2401-001397 C-AL;470UF,20%,25V,GP,10X16MM,
6 C106 2401-001513 C-AL;47UF,20%,16V,WT,5X11MM,5M
7-8
Remark Loc. No. Code No.
6 C645
6 C646
6 C647
6 C648
6 C649
6 C650
6 C642
6 C643
6 C644
6 C690
6 C720
6 C691
6 C831
6 C808
6 C809
6 C812
6 C813
6 C816
6 C817
6 C111
6 C823
6 C834
6 C662
6 C706
6 C826
6 C901
6 C903
6 L105
6 L107
6 L108
6 L111
6 L112
6 L113
6 L114
6 L119
6 L120
6 L121
6 L122
6 L123
6 L124
6 L101
6 L103
6 L104
6 L106
6 L703
6 L705
6 L706
6 L102
6 L128
6 L605
6 L606
6 CN101
6 CN903
6 CN601
6 CN201
6 GT01
6 GT02
6 GT03
6 A/SMD
7 DZ102
7 DZ103
7 DZ104
7 DZ105
7 DZ106
7 DZ107
7 DZ108
7 DZ109
7 DZ701
7 DZ704
7 DZ601
7 DZ603
7 DZ702
7 DZ703
7 DZ707
7 DZ602
7 DZ604
7 DZ705
Description ; Specification
2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
2401-001989 C-AL;4.7uF,20%,50V,BP,TP,5x11,5
2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5mm
2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5mm
2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5mm
2401-002075 C-AL;4.7uF,20%,50V,GP,TP,5x11,5mm
2401-002144 C-AL;47uF,20%,16V,GP,TP,5x11,5
2401-002300 C-ELECTROLYTIC;CE04WTAPG50V47U
2401-002300 C-ELECTROLYTIC;CE04WTAPG50V47U
2401-002459 C-AL;220UF,20%,25V,WT,10X16MM,
2401-002459 C-AL;220UF,20%,25V,WT,10X16MM,
2401-002459 C-AL;220UF,20%,25V,WT,10X16MM,
2401-002459 C-AL;220UF,20%,25V,WT,10X16MM,
2401-002459 C-AL;220UF,20%,25V,WT,10X16MM,
2401-002459 C-AL;220UF,20%,25V,WT,10X16MM,
2401-002463 C-ELECTROLYTIC;CE04WTAPG16V470M-M(SG)-VE
2401-002463 C-ELECTROLYTIC;CE04WTAPG16V470M-M(SG)-VE
2401-002594 C-AL;220uF,20%,16V,GP,TP,8x11.5,5
2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
2401-002619 C-AL;47uF,20%,25V,GP,TP,5x11,5
2701-000106 INDUCTOR-AXIAL;1.5uH,10%,2.8x7mm
2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3.
2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3.
2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3.
2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3.
2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3.
2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3.
2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3.
2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3.
2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3.
2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3.
2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3.
2701-000114 INDUCTOR-AXIAL;10UH,10%,2.5X3.
2701-000115 INDUCTOR-AXIAL;10UH,10%,2.8X7M
2701-000115 INDUCTOR-AXIAL;10UH,10%,2.8X7M
2701-000115 INDUCTOR-AXIAL;10UH,10%,2.8X7M
2701-000115 INDUCTOR-AXIAL;10UH,10%,2.8X7M
2701-000115 INDUCTOR-AXIAL;10UH,10%,2.8X7M
2701-001030 INDUCTOR-AXIAL;43uH,10%,14x4.5mm
2701-001030 INDUCTOR-AXIAL;43uH,10%,14x4.5mm
2701-001040 COIL INDUCTOR; COIL,10uH,ALO5
3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6.
3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6.
3301-000287 CORE-FERRITEBEAD;AA,3.5X1.0X6.
3711-002642 POST-HEADER;67094-003(AUTO)
3711-002642 POST-HEADER;67094-003(AUTO)
3711-002643 POST-HEADER;YW025-04(AUTO)
3711-002645 POST-HEADER;67094-006(AUTO)
AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO
BP97-00097A ASSY SMD;HCM422WX/XAA,P55A,SMD,P55A
0403-000314 DIODE-ZENER;RLZJ9.1B,9.1V,8.80-9.30V,400
0403-000314 DIODE-ZENER;RLZJ9.1B,9.1V,8.80-9.30V,400
0403-000314 DIODE-ZENER;RLZJ9.1B,9.1V,8.80-9.30V,400
0403-000314 DIODE-ZENER;RLZJ9.1B,9.1V,8.80-9.30V,400
0403-000314 DIODE-ZENER;RLZJ9.1B,9.1V,8.80-9.30V,400
0403-000314 DIODE-ZENER;RLZJ9.1B,9.1V,8.80-9.30V,400
0403-000314 DIODE-ZENER;RLZJ9.1B,9.1V,8.80-9.30V,400
0403-000314 DIODE-ZENER;RLZJ9.1B,9.1V,8.80-9.30V,400
0403-000314 DIODE-ZENER;RLZJ9.1B,9.1V,8.80-9.30V,400
0403-000314 DIODE-ZENER;RLZJ9.1B,9.1V,8.80-9.30V,400
0403-001016 DIODE-ZENER;RLZ6.2B,6.2V,5.96-6.27V,400m
0403-001016 DIODE-ZENER;RLZ6.2B,6.2V,5.96-6.27V,400m
0403-001016 DIODE-ZENER;RLZ6.2B,6.2V,5.96-6.27V,400m
0403-001016 DIODE-ZENER;RLZ6.2B,6.2V,5.96-6.27V,400m
0403-001016 DIODE-ZENER;RLZ6.2B,6.2V,5.96-6.27V,400m
0403-001117 DIODE-ZENER;RLZ12B,5%,500mW,LL-34,TP
0403-001117 DIODE-ZENER;RLZ12B,5%,500mW,LL-34,TP
0403-001117 DIODE-ZENER;RLZ12B,5%,500mW,LL-34,TP
Remark
