COLOR TELEVISION RECEIVER
COLOR TELEVISION RECEIVER
Chassis :
KS1A(P)_Rev.2
Model :
CS14Y530X/BWT
CS14Y510X/BWT
CS14H40X/BWT,CS14H40S/ATG
CS21D90X/BWT
CS14V5MJ0X/CBM
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
CONTENTS

Advertisement

Table of Contents
loading

Related Manuals for Samsung CS14Y530X/BWT

Summary of Contents for Samsung CS14Y530X/BWT

  • Page 1: Table Of Contents

    COLOR TELEVISION RECEIVER Chassis : KS1A(P)_Rev.2 Model : CS14Y530X/BWT CS14Y510X/BWT CS14H40X/BWT,CS14H40S/ATG CS21D90X/BWT CS14V5MJ0X/CBM COLOR TELEVISION RECEIVER CONTENTS Precautions Specifications and IC Data Disassembly and Reassembly Alignment and Adjustment Troubleshooting Exploded View and Parts List Electrical Parts List Block Diagram Wiring Diagram...
  • Page 2 ELECTRONICS This Service Manual is a property of Samsung Electronics Co.,Ltd. © Samsung Electronics Co., Ltd. Aug. 2003 Printed in Korea Any unauthorized use of Manual can be punished under applicable AA82-00885C International and/or domestic law.

  • Page 3: Precautions

    Precautions 1. Precautions Follow these safety, servicing and ESD precautions to prevent damage and protect against potential hazards such as electrical shock and X-rays. 1-1 Safety Precautions 1. Be sure that all of the built-in protective devices are replaced. Restore any missing (READING SHOULD NOT BE ABOVE protective shields.
  • Page 4 14. Components, parts and wiring that appear to have overheated or that are otherwise damaged should be replaced with parts that meet the original specifications. Always determine the cause of damage or overheat- ing, and correct any potential hazards. Samsung Electronics...

  • Page 5: Servicing Precautions

    Precautions 1-2 Servicing Precautions Warning1: First read the “Safety Precautions” section of this manual. If some unforeseen circumstance creates a conflict between the servicing and safety precautions, always follow the safety precautions. Warning2: An electrolytic capacitor installed with the wrong polarity might explode. 1.
  • Page 6 4. Do not use freon-propelled chemicals. These unpackaged replacement ESDs. Motions such can generate electrical charges that damage as brushing clothes together, or lifting a foot ESDs. from a carpeted floor can generate enough static electricity to damage an ESD. Samsung Electronics...

  • Page 7: Specifications And Ic Data

    Black stripe, 90 degree deflection 21 Inch A51KQJ63X Power Requirements: AC 100~240V, 50/60Hz Antenna Input Impedance: VHF, UHF : Telescopic dipole antenna (75 ohm unbalanced type ) Speaker Impedance 8 ohm, 5W+5W (Dual Type) 16 ohm, 3W (Monitor Type & Dual Type) Samsung Electronics...
  • Page 8 SOUND-AMP (3W x 1CH or 3W x 2CH or 5W x 2CH) KA5Q0765R POWER IC (STR) IC801S CUSTOM REGULATOR (5V, 8V, 3.3V) IC802 KA7632 IC902 24C08/KS28C040 EEPROM PC801S TCET1108 / LTV817B PHOTO COUPLER SIF - IC IC101 U4468B TEMIC Samsung Electronics...
  • Page 9 KS24C080(Pin 8) U4468B(Pin 16) TRANSISTOR SAW-FILTER TRANSISTOR G3956M K9260M 2SD1651 UPC574J 2SD1650 2SD2499 KSC815-Y KA33V KSA614 KSA539-Y BC548 KTC9014 E B C TRANSISTOR LA7840 TDA6107Q KA7632 KSR1012 KSR1010 KSR2010 KTD863-Y KSC2331-Y E C B Fig. 2-1 Semiconductor Base Diagrams Samsung Electronics...
  • Page 10 MEMO...

  • Page 11: Disassembly And Reassembly

    Disassembly and reassembly 3. Disassembly and Reassembly 3-1 Back Cover Removal 1. After removing the screws, press the tension rib and pull the cabinet backwards. 2. To reassemble, press the tension rib (see diagram). Samsung Electronics...
  • Page 12 2. Remove the Anode Cap from the CRT. 3. Remove the main board by pulling it with both hands. Warning: The FBT is charged with high voltage. Before removing the Anode Cap, discharge the voltage through one of the heat sinks on the main board. Samsung Electronics...
  • Page 13 Disassembly and reassembly 3-3 Speaker Removal 1. Remove the speaker by pressing the tension rib. 1. Remove the screws. 2. Remove the speaker by pressing the tension rib. Samsung Electronics...
  • Page 14 Always lift the picture tube by grasping it firmly around the faceplate, (2) Never lift the tube by its neck. (3) Do not scratch the picture tube or apply excessive pressure. Fractures of the glass may cause an implosion. Samsung Electronics...

  • Page 15: Alignment And Adjustment

    “FACTORY” or “Power OFF” keys. 3. Access the Adjustment Mode by pressing the “VOLUME” keys ( Up or Down). The adjust- ment parameters are listed in the accompany- ing table, and selected by pressing the CHAN- NEL keys ( , ). Samsung Electronics...
  • Page 16 SE CAM - L V i s i o n I F L CO 0 ~ 1 T XP T T X P o s i t i o n 0 ~ 1 5 NOTE : PVS,PVA, PHS, parameters must be aligned using the 50Hz vertical-field rates. Samsung Electronics...
  • Page 17 Alignment and Adjustments 4-2-3 Option Bytes In the Service Mode, various can be selected via the Option Table. Example: Option Table : xx xx xx xx SYSTEM AUDIO MONO JACK ZOOM NOR/ZOOM/16:9 AUTO POWER 2nd SIF HOTEL MODE Samsung Electronics...
  • Page 18 7. Do not attempt to connect or disconnect any wires while the TV is turned on. Make sure that the power cord is disconnected before replacing any parts. 8. To protect against shock hazard, use an isola- tion transformer. Samsung Electronics...
  • Page 19 3. Use the P mode key (on the remote control) for the STANDARD picture. 4. Adjust the Screen VR (on the FBT) so that the voltage on the oscilloscope becomes 120+2.5V (See Fig. 4-1). 120 2.5V 14" :120 2.5V 20, 21" : 120 2.5V Fig. 4-1 Samsung Electronics...
  • Page 20 Fig. 4-4 2. Adjust RG,BG so that the levels are suitable to each local area. (c) High-Light Adjustment 1. Set SCT to 55 FL (20”. 21”), 65 FL(14”) in the Factory Service Mode with using CA100. See Fig. 4-4 Samsung Electronics...
  • Page 21 8. Since the 4-pole magnets and 6-pole magnets lines in the center area of the screen. interact, the dot movement is complex (Fig. 4-5). RED/BLUE GREEN BLUE BLUE RED/BLUE GREEN 6-Pole Magnet Movement 4-Pole Magnet Movement Fig. 4-5 Center Convergence Adjustment Samsung Electronics...
  • Page 22 4. Fig. 4-7 4. Adjust with VS (Vertical shift) so that the top margin of the picture is 4. Fig. 4-8 5. Adjust with HS (Horizontal Shift) so that the lion-head pattern and CRT centers are aligned. Samsung Electronics...

  • Page 23: Troubleshooting

    Measure the Check/Replace Voltage of Each Pin TU01S of TU01S Check IC201S Check/Replace Pins 2,3 IC201S See "No Sound" (Video OK) Check IC201S Check/Replace Pins 40,49,50 IC501, IC201S See "No Sound" See "No Video" (Video OK) (Sound OK) Samsung Electronics...
  • Page 24 IC802 (KA7632) Pin 9 (9V) Pin 10 (5V) Check IC201S Check/Replace Pin 1 (3.3V) IC201S Check IC201S Check/Replace Pin 1 : Stand-by : 0V IC201S, (µ-com). Normal : 3.3V Check/Replace Check IC201S, IC201S, Q401, Q402. Pin 33 (H-out) Samsung Electronics...
  • Page 25 IC201S Check IC201S Pins 38/R214, R215 Check IC201S Pin 49 (V-GUARD) Check/Replace Pin 50 (Cut-off) IC201S Pin 51~53 (R,G,B-out) Check IC501 Check/Replace on the CRT PCB IC501 Check/Replace R421, R505 (HEATER 6.3Vrms) D503 (CRT G1 pin) CRT, V999S Samsung Electronics...
  • Page 26 Pin 44 (Sound Out) IC201S Check/Replace Check IC601 Q904, IC201S Pins 6 (0V) Check IC601 Check/Replace Pin 3,13 (B+ 10-12.5V) R814, R815 Check/Replace Check IC601 IC601 Check/Replace A/V Front assembly. 5-5 No TTX Check/Replace Check IC201S IC201S See No Video Samsung Electronics...

  • Page 27: Exploded View And Parts List

    Exploded View & Parts List 6. Exploded View & Parts List 6-1 CS14Y530X/BWT You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr Code No Description Specification Q’ty Remark S.N.A AA91-00485P ASSY CABINET FRONT;,14Y5,LB-105A CIS KS1...
  • Page 28 Exploded View & Parts List 6-2 CS14H40X/BWT You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr Code No Description Specification Q’ty Remark S.N.A AA96-00956A ASSY COVER P-C/FRONT;14H4,HIPS HB,BLK,SP T0003 AA64-02797A CABINET-FRONT;14H4,HIPS,HB,BLK,BK708P ML AA64-70127F BADGE-BRAND;NEW,AL,T1.4,6.3,L40,R800,SIL T0057 S.N.A...
  • Page 29 Exploded View & Parts List 6-3 CS21D90X/BWT You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr Code No Description Specification Q’ty Remark S.N.A AA64-02159C CABINET FRONT;CS21D9X/BWT,HIPS,HB,BK-708 CIS3 AA64-70123B BADGE-BRAND;ALL,AL,8.5,L50,BLK,SILVER,SA T0057 S.N.A AA64-03278A KNOB POWER;CS21D9X/BWT,ABS,HB,K2901...
  • Page 30 Exploded View & Parts List 6-4 CS14V5MJ0X/CBM You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr Code No Description Specification Q’ty Remark S.N.A AA96-01337A ASSY COVER P-FRONT;14V5(TSE),HB,G4309,(S M0011 AA64-03115A CABINET-FRONT;14V5(TSE),HIPS,HB,G4309,SV S.N.A AA64-70127F BADGE-BRAND;NEW,AL,T1.4,6.3,L40,R800,SIL T0057 S.N.A...

  • Page 31: Electrical Parts List

    Electrical Parts List You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr 7. Electrical Parts List 7-1 CS14V5MJ0X/CBM Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification...
  • Page 32 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M ..4 R125 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R075 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M ..4 R125 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R075 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP,2.4X6.4M ..4 R125 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R075 2001-000022 R-CARBON(S);33OHM,5%,1/2W,AA,TP,2.4X6.4M ..4 R125 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R075 2001-000037 R-CARBON(S);330OHM,5%,1/2W,AA,TP,2.4X6.4 ..4 R125 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...
  • Page 33 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP ..4 C701 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m ..4 C689 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V ..4 C701 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5 ..4 C689 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V ..4 C701 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5 ..4 C689 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V ..4 C701 2401-000481 C-AL;10uF,20%,50V,WT,TP,5x11,5 ..4 C689 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V ..4 C701 2401-000560 C-AL;1uF,20%,160V,GP,TP,6.3x11,5 Samsung Electronics...
  • Page 34 AA65-30111A CLAMPER CORE-WIRE;ALL MODEL,NYLON,V0,-,W S.N.A ..4 EY823 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A ..2 T0066 AA96-20109B ASSY POWER CORD;-,CP2/NO(4.0),H/C250,KKP S.N.A ..4 EY824 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A ...3 3811-000401 WIRE-PVC CU;BCWA,300V,ROLL,17/0.16mm,#22 S.N.A ..4 EY818 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A ...3 T0077 AA39-10006X CBF POWER CORD;-,KKP419C,KLCE-2F,2.286MT Samsung Electronics...
  • Page 35 ..2 T0074 AA59-00104J REMOCON;,TM59,SIM806E,24,L/GRAY,EX,GRAY ..2 T0563 AA68-01602B MANUAL USERS;,ENG,W/P100G,ALL1,B5,KS1A,3 ..2 T0563 AA68-01795A MANUAL USERS;,FRE.,W/P100G,ALL1,B5,KS1A, S.N.A 6902-000009 BAG PE;HDPE,T0.03,L400,W240,TRP,8,2,PE M S.N.A 6801-001063 CARD-REGISTRATION;-,SAMSUNG,ENG+ARAB,MOJ S.N.A ASSY P/MATERIAL AA92-07559A ASSY P/MATERIAL;14V5 S.N.A AA60-40006A PIN-STAPLE;AUTO,33X17.8X2.4,H18,33X17.8X S.N.A 6902-000061 BAG AIR;LDPE,T0.2,L1000,W500,TRP,,, S.N.A 6902-000001 BAG AIR;LDPE,T0.2,L1800,W1000,TRP,,,LDPE S.N.A 6902-000003 BAG PE;HDPE/NITRON/HDPE,T0.015/T0.5/T0.0...
  • Page 36 Description ; Specification Remark ASSY COVER FRONT ..2 T0073 AA94-13541A ASSY PCB MAIN;CTV ...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A M0001 AA90-01810M ASSY COVER FRONT;CS14Y530X/BWT S.N.A ...3 T0090 0502-001160 TR-POWER;2SD2499,NPN,50000mW,TO-3P,BK,8- ...3 IC112 1103-001106 IC-EEPROM;C81DC,1028x8Bit,DIP,8P,300MIL, ..2 T0081 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR ...3 NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T ..2 T0081...
  • Page 37 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x ..4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R303 2003-002152 R-METAL OXIDE;1OHM,5%,2W,AG,TP,6X16MM ..4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R402 2003-002178 R-METAL OXIDE(S);1Kohm,5%,2W,AG,TP,3.9x1 ..4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R407 2003-002209 R-METAL OXIDE(S);47Kohm,5%,2W,AG,TP,3.9X ..4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R811 2003-002239 R-METAL OXIDE(S);100KOHM,5%,2W,AF,TP,3.9 Samsung Electronics...
  • Page 38 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x ..4 FD801S 3601-001163 FUSE-AXIAL LEAD;125V,7A,-,EPOXY,2.4X7.1M ..4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x ..4 F801B 3602-000114 FUSE-HOLDER;-,-,30mohm ..4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x ..4 F801A 3602-000114 FUSE-HOLDER;-,-,30mohm ..4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x ..4 CN906 3711-002642 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGH ..4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x ..4 CN906 3711-002642 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGH Samsung Electronics...
  • Page 39 AA68-00816B CARD WARRANTY-01;,RUSSINA,2,W/P 120G,BOT S.N.A ...3 SWC02 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST 6801-001073 CARD-REGISTRATION;RUS,XEV,RUS,MOJO100,-, S.N.A ...3 SWC03 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST ..2 T0563 AA68-01296E MANUAL USERS;15K2/15K9,RUS,W/P100G,KS1A/ ...3 SWC04 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST ...3 SWC05 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST ...3 CCM 6001-000057 SCREW-MACHINE;RH,+,M3,L6,ZPC(BLK),SWRCH1 S.N.A ...3 T0245 AA39-00106C LEAD CONNECTOR-ASSY;,4P,200/180MM,YBNH25 Samsung Electronics...
  • Page 40 Electrical Parts List You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr 7-3 CS14Y510X/BWT Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark ASSY COVER FRONT ..2 T0073...
  • Page 41 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x ..4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R303 2003-002152 R-METAL OXIDE;1OHM,5%,2W,AG,TP,6X16MM ..4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R402 2003-002178 R-METAL OXIDE(S);1Kohm,5%,2W,AG,TP,3.9x1 ..4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R407 2003-002209 R-METAL OXIDE(S);47Kohm,5%,2W,AG,TP,3.9X ..4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R811 2003-002239 R-METAL OXIDE(S);100KOHM,5%,2W,AF,TP,3.9 Samsung Electronics 7-11...
  • Page 42 ..4 FD801S 3601-001163 FUSE-AXIAL LEAD;125V,7A,-,EPOXY,2.4X7.1M ..4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x ..4 F801B 3602-000114 FUSE-HOLDER;-,-,30mohm ..4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x ..4 F801A 3602-000114 FUSE-HOLDER;-,-,30mohm ..4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x ..4 CN906 3711-002642 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGH ..4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x ..4 CN906 3711-002642 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGH 7-12 Samsung Electronics...
  • Page 43 AA68-00816B CARD WARRANTY-01;,RUSSINA,2,W/P 120G,BOT S.N.A ...3 SWC02 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST 6801-001073 CARD-REGISTRATION;RUS,XEV,RUS,MOJO100,-, S.N.A ...3 SWC03 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST ..2 T0563 AA68-01296E MANUAL USERS;15K2/15K9,RUS,W/P100G,KS1A/ ...3 SWC04 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST ...3 SWC05 3404-000176 SWITCH-TACT;12V,50mA,120gf,6x6mm,SPST ...3 CCM 6001-000057 SCREW-MACHINE;RH,+,M3,L6,ZPC(BLK),SWRCH1 S.N.A ...3 T0245 AA39-00106C LEAD CONNECTOR-ASSY;,4P,200/180MM,YBNH25 Samsung Electronics 7-13...
  • Page 44 Electrical Parts List You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr 7-4 CS21D90X/BWT Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark ASSY COVER FRONT ...3 LX801S...
  • Page 45 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R024 2004-001371 R-METAL(S);1.5Kohm,1%,1/2W,AA,TP,2.4x6.4 ..4 R125 2001-000319 R-CARBON;120KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R024 2004-001371 R-METAL(S);1.5Kohm,1%,1/2W,AA,TP,2.4x6.4 ..4 R125 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R024 2004-001373 R-METAL(S);100Kohm,1%,1/2W,AA,TP,2.4x6.4 ..4 R125 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R024 2004-001402 R-METAL(S);6.8Kohm,1%,1/2W,AA,TP,2.4x6.4 ..4 R125 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R219 2004-001914 R-METAL;39Kohm,2%,1/8W,AA,TP,1.8x3.5mm Samsung Electronics 7-15...
  • Page 46 ..4 SW904 3404-001252 SWITCH-TACT;12VDC,50MA,130GF,7.5X7.1,1 ..4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x ..4 SW905 3404-001252 SWITCH-TACT;12VDC,50MA,130GF,7.5X7.1,1 ..4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V,TP,7.5x4.0x ..4 FD801S 3601-001163 FUSE-AXIAL LEAD;125V,7A,-,EPOXY,2.4X7.1M ..4 C701 2401-000025 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 ..4 F801A 3602-000114 FUSE-HOLDER;-,-,30mohm ..4 C701 2401-000025 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 ..4 F801B 3602-000114 FUSE-HOLDER;-,-,30mohm 7-16 Samsung Electronics...
  • Page 47 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A ..5 AA62-00065A HEAT SINK-PS;DP,-,-,-,AA62-00045A,-,-,-, S.N.A ..6- AA62-00045A HEAT SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-, S.N.A ..4 IC601 AA96-00244G ASSY H/S;-,AUDIO,AA62-00046A,TDA8944J,BR S.N.A ..5 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A ..5 T0085 1201-001741 IC-AUDIO AMP;TDA8944J,DBS,17P,937MIL,DUA ..5 T0081 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A ..5 AA61-10162B BRACKET-IC;-,SBHG-1,T1.0,-,-,-,100 S.N.A Samsung Electronics 7-17...
  • Page 48 Electrical Parts List You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr 7-5 CS14H40X/BWT,CS14H40S/ATG Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark ASSY COVER REAR...
  • Page 49 2001-000022 R-CARBON(S);33OHM,5%,1/2W,AA,TP,2.4X6.4M ..4 R125 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R075 2001-000037 R-CARBON(S);330OHM,5%,1/2W,AA,TP,2.4X6.4 ..4 R125 2001-001006 R-CARBON;82OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R125 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R125 2001-001006 R-CARBON;82OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R125 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R075 2001-001037 R-CARBON(S);0.39OHM,5%,1/2W,AA,TP,2.4X6..4 R125 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 R075 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4 Samsung Electronics 7-19...
  • Page 50 2301-000204 C-FILM,LEAD-PEF;2.7nF,5%,50V,TP,7.4x3.9x ..4 L904 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534 ..4 C2560 2301-000213 C-FILM,LEAD-PEF;220nF,5%,250V,TP,21.5x11 ..4 J142 2701-000115 INDUCTOR-AXIAL;10uH,10%,3070 ..4 C2560 2301-000233 C-FILM,LEAD-PEF;3.9nF,10%,100V,TP,5.8x12 ..4 L404 2701-000142 INDUCTOR-AXIAL;1uH,10%,2534 ..4 C2560 2301-000253 C-FILM,LEAD-PEF;39NF,5%,100V,TP,7.5X4.5X ..4 L302 2701-000142 INDUCTOR-AXIAL;1uH,10%,2534 ..4 C2560 2301-000289 C-FILM,LEAD-PEF;5.6nF,5%,50V,TP,7x6x3,5 ..4 L301 2701-000142 INDUCTOR-AXIAL;1uH,10%,2534 7-20 Samsung Electronics...
  • Page 51 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A ..4 EY423 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A ..4 EY501 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A ..4 EY801 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A ..4 EY802 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A ..4 EY420 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A ..4 EY412 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A ..4 EY414 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A Samsung Electronics 7-21...
  • Page 52 Electrical Parts List MEMO 7-22 Samsung Electronics...

  • Page 53: Block Diagram

    Block Diagram 8. Block Diagram 8-1 KS1A T U NE R -F /S SI F SA W V E R T IC AL T A E L -G 2 5 3 D K9260M A M P S/ W V I F SA W G3956M L A7840 (Option)

  • Page 54: Wiring Diagram

    SOUND L OUT SOUND L IN SOUND R OUT SOUND R IN CN603 FRONT AUDIO IN R + OUT R - OUT 21 PIN AUDIO IN L + OUT L - OUT 21 PIN VIDEO IN FRONT VIDEO IN Samsung Electronics...
  • Page 55 MEMO...

  • Page 56: Schematic Diagrams

    Schematic Diagrams 10. Schematic Diagrams 10-1 IF & VIF/SIF & CHROMA TP07 TP12 TP13 TP03 TP04 TP11 TP06 TP08 TP05 TP10 TP09 TP14 TP01 TP02 Samsung Electronics 10-1...
  • Page 57 Schematic Diagrams 10-1-1 IF & VIF/SIF & CHROMA WAVEFORMS TP07 TP13 TP01 TP08 TP14 TP02 TP09 TP03 TP10 TP04 TP11 TP05 TP12 TP06 10-2 Samsung Electronics...
  • Page 58 Schematic Diagrams 10-2 A/V(RCA)-SW & SUB ASSY TP15 TP15 TP16 TP16 Samsung Electronics 10-3...
  • Page 59 Schematic Diagrams 10-3 A/V(SCART)-SW & SUB-ASSY TP15 TP15 TP16 TP16 10-4 Samsung Electronics...
  • Page 60 Schematic Diagrams 10-4 POWER & V/H-DEFLECTION & CRT TP17 TP22 TP18 TP19 TP21 TP20 TP20 TP19 TP21 TP18 TP22 TP17 Samsung Electronics 10-5...
  • Page 61 Schematic Diagrams 10-5 IF & VIF/SIF & CHROMA(MAC ARTHUR) TP07 TP12 TP13 TP03 TP04 TP11 TP08 TP06 TP05 TP10 TP09 TP14 TP01 TP02 10-6 Samsung Electronics...
  • Page 62 Schematic Diagrams 10-5-1 IF & VIF/SIF & CHROMA WAVEFORMS(MAC ARTHUR) TP07 TP13 TP01 TP08 TP14 TP02 TP09 TP03 TP10 TP04 TP11 TP05 TP12 TP06 Samsung Electronics 10-7...
  • Page 63 Schematic Diagrams 10-6 A/V(RCA)-SW & SUB ASSY(MAC ARTHUR) TP15 TP15 TP16 TP16 10-8 Samsung Electronics...
  • Page 64 Schematic Diagrams 10-7 A/V(SCART)-SW & SUB-ASSY(MAC ARTHUR) TP15 TP15 TP16 TP16 Samsung Electronics 10-9...
  • Page 65 Schematic Diagrams 10-8 POWER & V/H-DEFLECTION & CRT(MAC ARTHUR) TP17 TP18 TP19 TP22 TP21 TP20 TP20 TP19 TP21 TP18 TP22 TP17 10-10 Samsung Electronics...
