DIGITAL-LOGIC AG
2 O
VERVIEW
2.1

Standard Features

The MICROSPACE EPIC is a miniaturized modular device incorporating the major elements of a PC/AT
compatible computer. It includes standard PC/AT compatible elements, such as:
AMD GEODE LX800 with 500MHz
-
BIOS ROM
-
DDRAM 256 – 1024MByte DDR-DIMM 200pin
-
128kByte second level cache
-
- Timers
- DMA
- Real-time clock with CMOS-RAM and 10year battery buffer
- LPT1 parallel port
COM1-, COM2- RS232 serial port 16C550 comp.
-
COM3-, COM4- TTL (V1.0 also RS232) , with ext. converters for RS422 or RS485.
-
- Speaker interface
- AT-keyboard interface or PS/2-keyboard interface
- Floppy disk interface
- AT-IDE harddisk interface
VGA videointerface, optional DVI, VGA, LVDS
-
2 channel soundinterface AC97
-
- 100/10-Base-T LAN
- Optional 1GB-LAN
- PC/104 (ISA and PCI) BUS optional
- PS/2 mouse interface
- Power management functions APM and ACPI
- 2-6 channel USB V1.1 & V2.0
2.2

Unique Features

The MICROSPACE MSEP800 includes all standard PC/AT functions plus unique DIGITAL-LOGIC AG en-
hancements, such as:
- Single 10V to 30V supply
- Watchdog
- Power-fail detection
EEPROM for setup and configuration
-
Optional: Compact Card holder typ 2
-
Digital I/O 24Bit
-
UL approved parts
-
Console redirection
-
10
MSEP800 Manual V1.0G
