DIGITAL-LOGIC MICROSPACE MSEP800 Technical User's Manual page 73

DIGITAL-LOGIC AG
J20 IrDa
Pin Signal
Pin 1 = VCC 5V
Pin 3 = IR RX
BIOS settings:
You have to enable the UART A of the GeodeLX in the bios setup:
F1 -> Motherboard device configuration -> I/O configuration:
UART port A = enabled
-
UART mode = SIR/CIR
-
ATTENTION !
Do never set the UART A mode to "Serial – 16550 compatible" or "Extended" if a IrDa diode is con-
nected to the J20. Otherwise the diode will be destroyed!
X6 MiniPCI interface
Pin: Signal:
1 TIP
3 8PMJ-3
5 8PMJ-6
7 8PMJ-7
9 8PMJ-8
11 LED1_GRNP
13 LED1_GRNN
15 CHSGND
17 INTB#
19 3.3V
21 RESERVED
23 GROUND
25 CLK
27 GROUND
29 REQ#
31 3.3V
33 AD[31]
35 AD[29]
37 GROUND
39 AD[27]
41 AD[25]
43 RESERVED
45 C/BE[3]#
47 AD[23]
49 GROUND
51 AD[21]
53 AD[19]
55 GROUND
57 AD[17]
59 C/BE[2]#
61 IRDY#
Pin
Pin 2
Pin 4
Pin: Signal:
2 RING
4 8PMJ-1
6 8PMJ-2
8 8PMJ-4
10 8PMJ-5
12 LED2_YELP
14 LED2_YELN
16 RESERVED
18 5V
20 INTA#
22 RESERVED
24 3.3VAUX
26 RST#
28 3.3V
30 GNT#
32 GROUND
34 PME#
36 RESERVED
38 AD[30]
40 3.3V
42 AD[28]
44 AD[26]
46 AD[24]
48 IDSEL
50 GROUND
52 AD[22]
54 AD[20]
56 PAR
58 AD[18]
60 AD[16]
62 GROUND
Signal
= IR TX
= GND
Pin: Signal:
63 3.3V
65 CLKRUN#
67 SERR#
69 GROUND
71 PERR#
73 C/BE[1]#
75 AD[14]
77 GROUND
79 AD[12]
81 AD[10]
83 GROUND
85 AD[08]
87 AD[07]
89 3.3V
91 AD[05]
93 RESERVED
95 AD[03]
97 5V
99 AD[01]
101 GROUND
103 AC_SYNC
105 AC_SDATA_IN
107 AC_BIT_CLK
109 AC_CODEC_ID1#
111 MOD_AUDIO_MON 112
113 AUDIO_GND
115 SYS_AUDIO_OUT
117 SYS_AUDIO_OUT
GND
119 AUDIO_GND
121 RESERVED
123 VCC5VA
73
MSEP800 Manual V1.0G
Pin: Signal:
64 FRAME#
66 TRDY#
68 STOP#
70 3.3V
72 DEVSEL#
74 GROUND
76 AD[15]
78 AD[13]
80 AD[11]
82 GROUND
84 AD[09]
86 C/BE[0]#
88 3.3V
90 AD[06]
92 AD[04]
94 AD[02]
96 AD[00]
98 RESERVED_WIP5
100 RESERVED_WIP5
102 GROUND
104 M66EN
106 AC_SDATA_OUT
108 AC_CODEC_ID0#
110 AC_RESET#
RESERVED
114 GROUND
116 SYS_AUDIO_IN
118 SYS_AUDIO_IN
GND
120 AUDIO_GND
122 MPCIACT#
124 3.3VAUX
