DIGITAL-LOGIC MICROSPACE MSEP800 Technical User's Manual page 14

DIGITAL-LOGIC AG
External Interface
Videointerfaces
USB V1.1/2.0
MSEP800
MSEP800L
LPT1:
COM1:
COM2:
COM3:
MSEP800
MSEP800L
COM4:
MSEP800
MSEP800L
Keyboard:
Mouse:
Floppy:
Parallel-Harddisk:
Serial-Harddisk:
Speaker:
ISA-Bus:
PCI-Bus:
Mini-PCI Slot
MSEP800
MSEP800L
Powersupply:
Input voltage:
Input inrush current:
Protection:
Spec.
3.3Volt Power Output:
Power Consumption
With 256Mbyte
Standby
Poweroff (if VCC 12V)
Poweroff (if VCC 19V)
Poweroff (if VCC 24V)
Specification
CRT
4 USB channels
2 USB channels
IEEE1293 Printer
RS232
RS232
TTL (RS232 from Ver.1.0)
none
TTL (RS232 from Ver.1.0)
none
PS/2
PS/2
26pin FCC Interface for TEAC Minifloppy
1 channel 44pin RM2.0mm ATAIDE-cable
-
0.1Watt Speaker
PC/104
PC/104plus
1x
none
Nom. 10V-30V , max. Ripple=200mVpp
t.b.d.
EMI filtered
None
Not available
Specification
typical (8W) at 500MHz
Typical 3W.
Typical 7.3mA
Typical 8.6mA
Typical 9.6mA
14
MSEP800 Manual V1.0G
