DIGITAL-LOGIC MICROSPACE MSEP800 Technical User's Manual page 15

DIGITAL-LOGIC AG
Physical Characteristics
Dimensions:
Weight:
Operating Environment
Relative Humidity:
Vibration operating:
Vibration nonoperating: IEC68-2-6 10-50Hz, 0.15mm and 55-500Hz,
Shock operating:
Shock nonoperating:
Altitude
Temperature operating
Extended Temp. option MIL-810-501/502 see separate table below
Temperature storage
*) The backupbattery is limited on –40° C to +80° C o perating and storage temperature !
Specification
PC/104plus
Length: 165mm
Depth: 115mm
Height: 36mm
200gr
Specification
5 - 90% non condensing
IEC68-2-30 at -20° to +50°C operating
IEC68-2-6 10-50Hz, 0.075mm and 55-500Hz, 1.0G
IEC68-2-27 10G, 11ms ½ sine
IEC68-2-27 50G, 11ms, ½ sine
IEC68-2-13 4571meter operating
IEC68-2-1,2,14: MSEP855 Standard -20° C to +60° C
IEC68-2-1,2,14: -65° C to +125°C *)
15
MSEP800 Manual V1.0G
2.0G
