System requirements

• USB-equipped host computer system
• Any of the following operating systems:
• Windows® 10 (32-bit or 64-bit)
• Windows 8.1 (32-bit or 64-bit)
• Windows 8 (32-bit or 64-bit)
• Windows 7 (32-bit or 64-bit)
• Windows XP (32-bit or 64-bit)
• Windows Vista®
• Windows Server® 2012
• Windows Server 2008 R2
• Windows Server 2003
• Mac OS 10.7 and later (tested up to 10.11)
• Linux® 3.5
System requirements are subject to change. For the latest requirements, please visit
www.startech.com/ICUSB23216FD.

RS-232 pinout

PIN
1
2
3
4
5
6
7
8
9
Quick-start guide
Signal
DCD
RxD
TxD
DTR
GND
DSR
RTS
CTS
RI
