How To Disassemble The Mast - Genie GR-12 Service Manual

May 2018
11 Carefully pull the hydraulic hoses free while
removing the mast from the machine.
Crushing hazard. The mast
assembly could become
unbalanced and fall if not
properly supported when
removed from the machine.
Component damage hazard.
Hoses and cables can be
damaged if they are kinked or
pinched.
12 Place the mast assembly on a suitable
structure capable of supporting it.
Part No. 1275811GT
How to Dis ass embl e the M ast

How to Disassemble the Mast

1 Remove the Mast. Refer to Repair Procedure,
How to Remove the Mast Assembly.
2 Rotate the mast until the carriage is facing up.
3 Remove the socket head retaining fastener
from the clevis block on the lift cylinder rod
end at the top of the number 1 column.
GR ™ • QS ™ R • QS ™ W
Service Manual
Mast Components
Bodily injury hazard. This
procedure requires specific repair
skills, lifting equipment and a
suitable workshop. Attempting
this procedure without these skills
and tools could result in death or
serious injury and significant
component damage. Dealer
service is strongly recommended.
79
