Performance Specifications - Genie GR-12 Service Manual

Service Manual
Specifications

Performance Specifications

Drive speed, maximum
Platform stowed, fast
Platform stowed, slow
Platform raised
Braking distance, maximum
High range on paved surface
Gradeability
Function speed, maximum from platform controls
(with 1 person in platform)
GR-12, QS-12R, QS-12W
Platform up (fast mode)
Platform up (slow mode)
Platform down
GR-15, QS-15R, QS-15W
Platform up (fast mode)
Platform up (slow mode)
Platform down
GR-20, QS-20R, QS-20W
Platform up (fast mode)
Platform up (slow mode)
Platform down
2
2.5 mph
40 ft / 10.9 sec
4 km/h
12.2 m / 10.9 sec
1.1 mph
40 ft / 24.8 sec
1.8 km/h
12.2 m / 24.8 sec
0.5 mph
40 ft / 55 sec
0.8 km/h
12.2 m / 55 sec
19 in ± 6 in
61 cm ± 30 cm
See Operator's Manual
19 to 21 seconds
30 to 32 seconds
17 to 19 seconds
20 to 22 seconds
31 to 33 seconds
18 to 20 seconds
23 to 25 seconds
32 to 34 seconds
20 to 22 seconds
GR ™ • QS ™
Rated work load at full height, maximum
GR-12, GR-15
(standard platform)
GR-12, GR-15, GR-20
(AWP platform)
GR-20
(standard platform)
QS-12R, QS-15R, QS-12W, QS-15W
stockpicker platform)
QS-20R, QS-20W
(stockpicker platform)
For operational specifications, refer to the
Operator's Manual.
R • QS ™ W
May 2018
500 lbs
227 kg
350 lbs
159 kg
350 lbs
159 kg
500 lbs
227 kg
350 lbs
159 kg
Part No. 1275811GT
