Pin Name Function
TIOB1_0
SCS7_1
S21 P4D
TIOB3_0
SOT7_1/SDA7_1
BIN1_2
INT13_2
S22 Ground
S23 MCU_VCC33
S24 P3D
TIOA3_1
RTO03_0
S25 VDD_MOD
S26 P3A
TIOA0_1
AIN0_0
RTO00_0
S27 P14
SOT0_1/SDA0_1
WyzBee™ WyzBee™
User Manual User Manual
Version 1.2 Version 1.2
Direction Description
Inout Base Timer Channel 1 TIOB pin.
This can be used only if S12 is
not configured as TIOB1_1.
Output Multi-function Serial interface
Channel 7 Chip Select
Inout General-purpose Input/Output
Inout Base Timer Channel 3 TIOB pin.
This can be used only if S3 is not
configured as TIOB3_0.
Output/Inout Multi-function Serial Interface
Channel 2 Output/Inout
Input QPRC Channel 1 BIN Input
Input External Interrupt 13
Ground Ground
Output 3.3V Power Supply
Inout General-purpose Input/Output
Inout Base Timer Channel 3 TIOA pin
Output Waveform generator output of
Multi-function timer 3
Output 3.3V Output Power supply
Inout General-purpose Input/Output
Inout Base Timer Channel 0 TIOA pin
Input QPRC Channel 0 AIN Input
Inout Waveform generator output of
Multi-function timer 0
Inout General-purpose Input/Output
Output/Inout Multi-function Serial Interface
Channel 0 Output/Inout
