Pin Name Function
AN08
S14 VDD_5V
S15 GND
S16 VIN_EXT
S12 P15
SCK0_1/SCL0_1
AN05
S17 VDD_3V3
S18 P4C
TIOB2_0
SCK7_1/SCL7_1
AIN1_2
S19 P4E
TIOB4_0
SIN7_1
ZIN1_2
INT11_1
WKUP2
S20 P4B
WyzBee™ WyzBee™
User Manual User Manual
Version 1.2 Version 1.2
Direction Description
Chanel 2 Clock output
Input ADC Input Channel 8
Output 5V Output Power Supply for
THING boards.
Ground Ground
Input External Power Supply. This can
be from different sources like
battery THING.
Inout General-purpose Input/Output
Output Multi-function Serial interface
Chanel 0 Clock output
Input ADC Input Channel 5
Output 3.3V Output Power supply
Inout General-purpose Input/Output
Inout Base Timer Channel 2 TIOB pin
Output Multi-function Serial interface
Chanel 7 Clock output
Input QPRC Channel 1 AIN Input
Inout General-purpose Input/Output
Inout Base Timer Channel 4 TIOB pin
Input Multi-function Serial interface
Channel 7 Input
Input QPRC Channel 1 ZIN Input
Input External Interrupt 11
Input Deep standby mode return
Channel 2 Input
Inout General-purpose Input/Output
