Pin Name Function
ZIN0_0
RTO02_0
S8 MCU_RESET_N
S9 P23
TIOA7_1
RTO00_1
AN15
S10 P44
TIOA4_0
RTO14_1
DAC0
S11 P16
SIN2_2
INT14_1
AN06
S12 P17
SOT2_2
AN07
WKUP3
S13 P18
SCK2_2/SCL2_2
WyzBee™ WyzBee™
User Manual User Manual
Version 1.2 Version 1.2
Direction Description
Input QPRC Channel 0 ZIN Input
Output Waveform generator output of
Multi-function timer 2
Input External reset
Inout General-purpose Input/Output
Inout Base Timer Channel 7 TIOA pin
Output Waveform generator output of
Multi-function timer 0
Input ADC Input Channel 15
Inout General-purpose Input/Output
Inout Base Timer Channel 4 TIOA pin
Output Waveform generator output of
Multi-function timer 14
Output DAC Output Channel 0
Inout General-purpose Input/Output
Input Multi-function Serial interface
Channel 2 Input
Input External Interrupt 14
Input ADC Input Channel 6
Inout General-purpose Input/Output
Output Multi-function Serial Interface
Channel 2 Output
Input ADC Input Channel 7
Input Deep standby mode return
Channel 3 Input
Inout General-purpose Input/Output
Output Multi-function Serial interface
