Redpine Signals WyzBee User Manual page 38

Pin Name Function
INT07_2
S3 P31
TIOB1_1
SIN3_1
INT09_2
S4 P33
TIOB3_1
SCK3_1/SCL3_1
INT04_1
S5 P32
TIOB2_1
SOT3_1/SDA3_1
INT10_1
S6 P3B
TIOA1_1
BIN0_0
RTO01_0
S7 P3C
TIOA2_1
WyzBee™ WyzBee™
User Manual User Manual
Version 1.2 Version 1.2
Direction Description
Input External Interrupt 7
Inout General-purpose Input/Output
Inout Base Timer Channel 1 TIOB pin.
This can be used only if S16 is
not configured as TIOB1_0.
Input Multi-function Serial interface
Channel 3 Input
Input External Interrupt 9
Inout General-purpose Input/Output
Inout Base Timer Channel 3 TIOB pin.
This can be used only if S17 is
not configured as TIOB3_0.
Output Multi-function Serial interface
Chanel 3 Clock output
Input External Interrupt 4
Inout General-purpose Input/Output
Inout Base Timer Channel 2 TIOB pin.
This can be used only if S14 is
not configured as TIOB2_0.
Output/Inout Multi-function Serial Interface
Channel 3 Output/Inout
Input External Interrupt 10
Inout General-purpose Input/Output
Inout Base Timer Channel 1 TIOA pin
Input QPRC Channel 0 BIN Input
Output Waveform generator output of
Multi-function timer 1
Inout General-purpose Input/Output
Inout Base Timer Channel 2 TIOA pin
Page 38
