3-24
If no GOTO or follow is in progress, the steering instruction is NO TARGET,
no steering arrows are shown, but the rhumb line indicator is shown.
The graphical XTE indication places arrows either side of the rhumb line
indicator and pointing towards it, dependent on the value of XTE. The first
arrow is shown when the XTE reaches 0.01nm, the second at .05nm and
subsequently at 0.1nm intervals .
Note: The steering instruction and graphical XTE indication are repeated on
all text-only displays.

Navigation data

The Navigation Data display comprises text data occupying the whole screen:
POSITION
COG 230° T
SOG 6.8 Kts
WAYPOINT
BRG 234° T
RNG 2.4 nm
Textual data provides Position, SOG, COG, Bearing and Range to waypoint,
Time, Fix status and the XTE indicator. Any unavailable data is replaced by
dashes, one per character. When there is no GPS fix but there is a value for the
last fix, this is shown instead; POSITION is replaced with LAST POSITION.
The (c) indicator only appears when the position has been user calibrated.
The Fix indicator shows the GPS Fix status and indicates either FIX OK or
NO FIX. In the case of a differential fix, D-FIX is displayed.
Note: Graphical XTE indicator is as per Waypoint data screen, see above.
50°45 .000 N
001°06 .000 W (c)
001
GPS FIX
TIME 14:32 12/12/99
STEER STARBOARD
RayChart 420/420D Chartplotter
D4703_1
