Page 1: Installation Guide
Installation Guide Avigilon High Definition H.264 PTZ IP Dome Camera Models: 1.0W-H3PTZ-DP20 and 2.0W-H3PTZ-DP20 920-0064A-Rev3... - Page 3 Plus IEEE802.3at Type 2 compliant Power Sourcing Equipment (PSE) rated 42.5-57 VDC, 25.5W min. • Any external power supply connected to this product may only be connected to another Avigilon product of the same model series. External power connections must be properly insulated. •...
- Page 4 (such as from a liquid spill or fallen objects), has been exposed to rain or moisture, does not operate normally, or has been dropped. • Do not use strong or abrasive detergents when cleaning the device body. • Use only accessories recommended by Avigilon.
-
Page 5: Fcc Notice
Changes or modifications made to this equipment not expressly approved by Avigilon Corporation or parties authorized by Avigilon Corporation could void the user’s authority to operate this equipment. Disposal and Recycling Information... - Page 6 The contents of this manual and the specifications of this product are subject to change without notice. Avigilon reserves the right to make changes without notice in the specifications and materials contained herein and shall not be...
-
Page 7: Table Of Contents
Table of Contents Overview ......1 Front View ....... . 1 Top View . -
Page 9: Overview
Overview Front View Serial Number Label Link LED Connection Status LED Feature Description Serial Number Label Product serial number and part number label. Link LED Indicates if there is an active connection in the Ethernet port. Connection Status LED Provides information about device operation. -
Page 10: Top View
Top View Lanyard Anchor Ethernet Port External I/O External Power Feature Description External Power Accepts an external power connection when Power over Ethernet is not available. Lanyard Anchor The safety lanyard attaches to the anchor to prevent the camera from falling during installation. Ethernet Port Accepts an Ethernet connection to a network. -
Page 11: Pendant Mount Adapter
Pendant Mount Adapter 1 1/2” NPT Mount Adapter Tamper Proof Screws Feature Description 1-1/2” NPT Mount Standard 1-1/2” NPT adapter for mounting the Adapter dome camera to a pendant mount bracket. Tamper Proof TORX tamper-resistant captive screws to fix the Screws dome camera to the NPT adapter. -
Page 12: Installation
• Teflon Sealing Tape • RJ-45 crimp-on plug and weather-resistant housing • External Power wiring harness, Avigilon Part #110-0017B • External I/O wiring harness, Avigilon Part #110-0018B Installation Steps Complete the following procedures to install the dome camera. Installing the Mount Adapter on page 4... - Page 13 camera connection. There should be a minimum of three turns around the entire threaded surface. When applying the Teflon sealing tape, be sure to wrap in the same direction that the mount will be tightened. This will ensure the tape does not unravel when installing the mating parts together.
- Page 14 Install the 1 1/2” NPT mount adapter. Connect the safety lanyard from inside the NPT mount adapter to the anchor on the PTZ dome camera.
-
Page 15: Connecting Cables
Connecting Cables Refer to the camera’s Top View on page 2 for the location of the different connectors. Make sure the safety lanyard is connected to the PTZ dome camera before you complete the following cable connections: If there are external input or output devices that need to be connected to the camera (for example: door contacts, relays, analog video, speakers, etc), connect the devices to the camera I/O connector cable. -
Page 16: Securing The Ptz Dome Camera
Securing the PTZ Dome Camera After the cable connections have been made, secure the PTZ dome camera to the mount. Push the PTZ dome camera into the 1 1/2” NPT mount adapter then twist until it locks into place. NOTE: Be careful not to trap any cables between the dome camera housing and the mount adapter. -
Page 17: Accessing The Live Video Stream
Additional information about setting up and using the device is available in the following guides: • Avigilon Camera Installation Tool User Guide • Avigilon Control Center Client User Guide • Avigilon High Definition H.264 Web Interface User Guide The manuals are available on the Avigilon website: http://avigilon.com/ #/support-and-downloads. -
Page 18: Cable Connections
Cable Connections Connecting External Power NOTE: This procedure is not required if Power over Ethernet (PoE) is used. If PoE is not available, the dome camera can be powered with 24 VAC or 24 VDC through the removable power connector: Remove as much insulation as required to splice the supplied power connector to the power adapter wires (not included). -
Page 19: Connecting To External Devices
Connecting to External Devices External devices, including audio and video devices, are connected to the camera through the I/O cable. The pinout for the I/O connector is shown in the following table. Table: External I/O Connector Wire Color Description White Audio/video analog ground return Brown Analog audio input... - Page 20 When the camera flicker control is set to 60 Hz, the video output signal is NTSC. When the flicker control is set to 50 Hz, the video output signal is PAL. Use the Avigilon Camera Installation Tool to configure the camera’s flicker control in the Image and Display...
-
Page 21: Led Indicators
LED Indicators Once the camera is connected to the network, the Connection Status LED will display the camera’s progress in connecting to the Network Video Management software. The following table describes what the LEDs indicate: Table: LED Indicators Connection Connection Description State Status LED... -
Page 22: Reset To Factory Default Settings
Reset to Factory Default Settings If the camera no longer functions as expected, you can choose to restore the camera to its factory default settings. Use the firmware revert button to reset the camera. NOTE: Be careful not to scratch the dome bubble. Firmware Revert Button Figure: The firmware revert microswitch between the status LEDs. -
Page 23: Setting The Ip Address Through The Arp/Ping Method
Setting the IP Address Through the ARP/Ping Method Complete the following steps to configure the camera to use a specific IP address: Locate and copy down the MAC Address (MAC) listed on the Serial Number Tag for reference. Open a Command Prompt window and enter the following commands: arp -s <New Camera IP Address>... -
Page 24: Specifications
Specifications Camera Lens 4.7-94mm, 20x zoom, F1.6 and automatic focus Network Network 100Base-TX Cabling Type CAT5 Connector RJ-45 ONVIF compliant (www.onvif.org) Security Password protection, HTTPS encryption, digest authentication, WS authentication, user access log Protocols IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, Zeroconf, ARP Streaming Protocols RTP/UDP, RTP/UDP multicast, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/... -
Page 25: Limited Warranty & Technical Support
Limited Warranty & Technical Support Avigilon warrants to the original consumer purchaser, that this product will be free of defects in material and workmanship for a period of 3 years from date of purchase. The manufacturer’s liability hereunder is limited to replacement of the product, repair of the product or replacement of the product with repaired product at the discretion of the manufacturer.
