Quick Set-up Guide
Thermostat 518
1.

Location

2.
Remove Mounting Base
3.
Installation to Wall
© 2016 tekmar 518 _ Q - 06/16
Exterior
Wall
Thermostat
Front
Behind
Door
Thermostat
Base
518 _ Q
06/16
Zoning
Replaces: 03/13
Interior
Wall
5 feet
1.5 m
Wall
