INSTALAB 700 QUICK START GUIDE
Safety notices are one of the primary ways to call attention to potential hazards.
This Safety Alert Symbol identifies important safety messages in this manual. When you see this
symbol, carefully read the message that follows. Be alert to the possibility of personal injury or death.
Use of the word WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
Use of the word CAUTION with the Safety Alert Symbol indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
Use of the word CAUTION without the safety alert symbol indicates a potentially hazardous situation which, if not
avoided, may result in equipment damage.
DISCLAIMER
DICKEY-john reserves the right to make engineering refinements or procedural changes that may not be reflected in this manual.
Material included in this manual is for informational purposes and is subject to change without notice.

INTRODUCTION

This quick start guide provides the minimum requirements to begin using the Instalab 700 NIR Grain Analyzer and is organized
according to typical sequential actions for installation, startup, analyzation, and results.
More detailed information is available in the Operator's manual that addresses:
Calibrations
Sample preparation
System setup
Analyzing
Database Storage and Record Deletion
Diagnostics
Troubleshooting
Maintenance
Instalab 700 Quick Start Guide
11001-1608-201702 Rev B
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INSTALAB 700 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dickey-John INSTALAB 700

  • Page 1 Material included in this manual is for informational purposes and is subject to change without notice. INTRODUCTION This quick start guide provides the minimum requirements to begin using the Instalab 700 NIR Grain Analyzer and is organized according to typical sequential actions for installation, startup, analyzation, and results.
  • Page 2 INSTALLATION Inspect the unit for damage that may have occurred during shipping. If damage is found, immediately file a claim with the carrier and notify your DICKEY-john sales representative and return unit in original packing materials. IMPORTANT: The Instalab and printer (optional) must not be used in hazardous (classified) locations as defined in Article 500 of the NFPA Handbook of the National Electrical Code.
  • Page 3 INSTALAB 700 QUICK START GUIDE NAVIGATION The user interacts with the IL700 via the LCD touch screen display. Screen interaction by finger touch or using a dull, pointed object, such as a stylus or retracted pen is recommended. Do not use any sharp objects on the display. Damage to screen can result.
  • Page 4 INSTALAB 700 QUICK START GUIDE STARTUP The Instalab IL700 is powered on by pressing the on/off switch located on the front panel. A series of Startup screens load after the system is turned on. A status bar will indicate the loading of forms and upon completion, the Instrument Information screen displays for several seconds before the Main Menu screen displays.
  • Page 5 INSTALAB 700 QUICK START GUIDE PASSWORD RESTRICTIONS Setting an administrator user name and password to restrict modification of system settings to an administrator are optional. The unit is shipped with an Admin user name of “GUEST” and password setting of “GUEST”. The Admin user name screen is found in the Setup.
  • Page 6 INSTALAB 700 QUICK START GUIDE Figure 5 Import Product INSTALAB 700 INSTALAB 700 INSTALAB INSTALAB Select Directory 0 Directories, 4 Files Exist. Push ENTER to Import view. Label File Directory Contents HRWW_4 IL700.HRWW_4.20110908 CORN IL700.CORN.20110505 HRWW IL700.HRWW.20110505 SOYBEANS IL700.SOYBEANS.20110505 \Hard Disk\Samples\...
  • Page 7 INSTALAB 700 QUICK START GUIDE Figure 7 Analyzation Process Screens INSTALAB 700 INSTALAB 700 Screen does not appear if drawer Ref Scanning ... Ref Scanning ... is open or reference already recorded Product : CORN File: IL700 .Corn.2101229 .cal INSTALAB 700...
  • Page 8 INSTALAB 700 QUICK START GUIDE RESULTS The Results screen displays a listing of sample test results and date relevant to a specific test (Counter, Date and Time, Sample ID, and Customer ID) To display Results: 1. At the Main Menu screen, press the Results button. The Results View screen default displays all stored test results.
