20
21 22
INSTALLING DERAILLEUR HANGER //
A C
Grease outer edges of derailleur Torque derailleur bolt (#130798) to
hanger (#130790) and loctite derailleur 11NM or 100 in/lbs (IMAGE #22).
bolt (#130798) if not pre loctite applied
(IMAGE #20).
B
Insert hanger (#130790) into back of
frame opening and match derailleur bolt
(#130798) on the front side threading
bolt into hanger (IMAGE #21).
1 2 / / P R I M E R 2 9 u s e r m a n u a l
23 24
R E A R A X L E //
A
The Primer uses a rear axle with an allen through opening on the hanger bolt,
expanding collet system similar to our which will allow you to tighten axle in
main pivot bolts. This ensures a secure a counterclockwise (rearward) direction
fit between the axle and frame (IMAGE to 100 in/lb (IMAGE #24). You may then
#23). To install rear axle, insert threaded grease and install the cone adjuster into
end of axle through non-drive side the opening on the non-drive side of the
dropout until it reaches female threaded axle, then insert M6x25mm bolt into cone
end of hanger. You can then insert a 5mm adjuster and tighten to 125 in/lbs.
torque
Achieving proper torque is vital to
ensuring the safe performance and
function of the PRIMER 29 frame.
Failure to do so could result in sub-
optimal performance of your frame
as well as premature wear and tear
of individual parts.
M8 HEX 7 Nm / 60 in/lbs
additional reference
M5 HEX 14 Nm / 125 in/lbs
In addition to this chart, all torque
values are laser etched onto
corresponding hardware for your
reference.

torque chart

7 Nm / 60 in/lbs
20 Nm / 175 in/lbs
7 Nm / 60 in/lbs
M8 HEX 7 Nm / 60 in/lbs
M5 HEX 14 Nm / 125 in/lbs
11 Nm / 100 in/lbs
M8 HEX 7 Nm / 60 in/lbs
M5 HEX 14 Nm / 125 in/lbs
I N T E N S E C Y C L E S / / 1 3
