shock setup
FOX FLOAT DPS 200 x 51mm
set up and tune
FOX FLOAT DPS EVOL LV
proper set up and tuning can vary
from shock to shock. Please
FOX
consult the Fox manual included
with your bike for complete
information about set up, tuning
and general maintenance or visit
www.foxracingshox.com
1 6 / / P R I M E R 2 9 u s e r m a n u a l
Travel 115 mm
Shock Stoke 51 mm
Shock Sag 20% when sitting on the bike
Fork Sag 25-30% when sitting on the bike
SHOCK: Primer 29 Factory FOX Sho x , FLOAT DPS, F-S, K, 3POS-ADJ EVOL LV, 200×51 mm CM, RM, CLIMB
SHOCK: Primer 29 Pro
FOX Sho x , FLOAT DPS, P-SE, A, 3POS-ADJ EVOL LV, 200×51 mm CM, RM, CLIMB
RIDER WEIGHT (LBS/KGS) SPRING (PSI) REBOUND (clicks out) SPRING (PSI)
100 LBS / 45 KGS 76 86
110 LBS / 50 KGS 88 98
120 LBS / 54 KGS 100 3 to 4 110
130 LBS / 59 KGS 112 122
140 LBS / 63.5 KGS 124 134
150 LBS / 68 KGS 136 146
160 LBS / 73 KGS 148 158
170 LBS / 77 KGS 161 171
180 LBS / 82 KGS
173 183
5 to 6
190 LBS / 86 KGS 185 195
200 LBS / 91 KGS 197 207
210 LBS / 95 KGS
209 219
220 LBS / 100 KGS 221 231
230 LBS / 104 KGS 233 243
240 LBS / 109 KGS 245 255
250 LBS / 113 KGS 257 267
260 LBS / 118 KGS 269 279
RS KAGE
7 to 8
270 LBS / 122 KGS 282 FOX DHX2 292
280 LBS / 127 KGS 294 304
290 LBS / 131.5 KGS 306 316
300 LBS / 136 KGS 318 328
130 mm
REBOUND (clicks out)
3 to 4
5 to 6
7 to 8
