set up
upper mount
lower mount
seatpost adjustable travel
make sure to insert seat post at least upper mount: 130mm
4" into the main frame. Anything less lower mount: 115mm
than this amount could cause damage
to the frame or even failure.

shock setup

rock shox monarch rt3 / R 200 x 51mm
set up and tune
proper set up and tuning can
vary from shock to shock. Please
consult the rockshox manual
included with your bike for complete
information about set up, tuning
and general maintenance or visit
www.sram.com/rockshox/products
Travel 115 mm
Shock Stoke 51 mm
Shock Sag 20% when sitting on the bike
Fork Sag 25-30% when sitting on the bike
SHOCK: Primer 29 Expert Rock Sho x Monarch RT3 200x 51 mm DB2 MM S 320
SHOCK: Primer 29
Rock Sho x Monarch R 200x 51 mm DB2 MM S 320
Foundation
RIDER WEIGHT (LBS/KGS) SPRING (PSI) REBOUND (clicks out) SPRING (PSI)
100 LBS / 45 KGS
103 98
110 LBS / 50 KGS 116 114
120 LBS / 54 KGS 130 2 to 3 130
130 LBS / 59 KGS
144 146
140 LBS / 63.5 KGS 157 162
150 LBS / 68 KGS 171 177
160 LBS / 73 KGS 185 193
170 LBS / 77 KGS 198 209
180 LBS / 82 KGS 212 225
3 to 4
190 LBS / 86 KGS 226 241
200 LBS / 91 KGS
239 256
210 LBS / 95 KGS 253 272
220 LBS / 100 KGS 267 288
230 LBS / 104 KGS
281 304
240 LBS / 109 KGS 294 319
250 LBS / 113 KGS 308 335
260 LBS / 118 KGS 322 351
5 to 6
270 LBS / 122 KGS 335 367
280 LBS / 127 KGS 349 383
290 LBS / 131.5 KGS 363 398
300 LBS / 136 KGS 376 414
I N T E N S E C Y C L E S
130 mm
REBOUND (clicks out)
2 to 3
3 to 4
5 to 6
