Intense Cycles PRIMER 29 User Manual page 6

6 8
7 9
C O N N E C T I N G R E A R T R I A N G L E C O N N E C T I N G R E A R T R I A N G L E
T O B O X L I N K // T O T O P L I N K //
A A
Follow previous step to connect rear Holding spacers (#130765) with squared
triangle to box link (IMAGES #6 & 7). edges against the bearing and the rounded
side facing outward (IMAGE #8), Swing
B Use 8mm HEX to install, then torque the seat stays up and align with the lower
pivot bolt (#130791) to 7 NM or 60 in/lbs. spacers. From the non drive side of top
link, install greased pivot bolt (#130791)
(IMAGE #9). Use an 8mm HEX to install.
B Use an 8mm HEX to install torque
main pivot bolt (#130791) to 7 NM or
60 in/lbs.
1 0 / / P R I M E R 2 9 u s e r m a n u a l
10 12
11 13
I N S TA L L I N G R E A R S H O C K //
A
Holding rear shock match forward end to forward shock mount, and install greased
M6x40mm bolt (#410050) through drive side of frame (IMAGE #10). Do not tighten.
B Match rear end of shock to desired travel setting (see below) on upper link and
install greased M6x45mm bolt (#410051) through non-drive side of link (IMAGE #11).
C
Torque shock bolts (#410050 & #410051) to 7 NM or 60 in/lbs (IMAGES #12 & 13).
adjustable travel NOTE
the top link of the PRIMER 29 features dual mounting positions. The Upper shock
mounting hole on top link is for LONG travel, the lower hole is for SHORT travel.
for more information see the set up guide on page 14.
15
14 16
T I G H T E N I N G S E AT S TAY S T O T O P L I N K //
A B
Grease and install adjuster cone Using hand pressure, squeeze the top
(#130807) into head of main pivot bolt of seat stay together at the lower top
(#130791) and greased M6x22mm bolt link location to eliminate side to side
(#410032) through the adjuster cone play (IMAGE #15) then use a 5mm HEX
into the main pivot bolt (IMAGE #14). to make snug.
C
Torque M6x22mm (#410032) to 14 NM
or 125 in/lbs (IMAGE #16).
17
18 19
INSTALLING ADJUSTER CONES ON LOWER LINK //
A B
Grease and install adjuster cone Torque M6x22mm (#410032) to 14 NM
(#130807) into head of main pivot bolt or 125 in/lbs (IMAGE #19).
(#130791) and greased M6x22mm bolt
(#410032) through the adjuster cone into
the main pivot bolt (IMAGES #17 & 18).
I N T E N S E C Y C L E S / / 1 1
