- Page 1 F-2000 MODEL RT INSTRUCTION MANUAL Blue-White Industries, Ltd. 5300 Business Drive Huntington Beach, CA 92649 Phone: 714-893-8529 FAX: 714-894-9492 E mail: sales@blue-white.com or techsupport@blue-white.com Website: www.blue-white.com...
-
Page 2: Table Of Contents
Theory of operation Model RT Operation 7.2.1 Model RT Applications 7.2.2 Model RT Features 7.2.3 How to Determine Calibration Constants 7.2.4 Programming the Model RT 7.2.5 Calibration Constants Programming flow chart Maintenance Troubleshooting F-2000 parts list . . . F-2000 exploded view... -
Page 3: Features
F-2000 Page 3 FEATURES Battery powered rate and total Weather resistant enclosure (NEMA 4X) Extended battery life mode Corrosion resistant PVDF sensor (screen blanks after 30 seconds) ! Corrosion resistant ABS enclosure ! Easy to read, eight digit LCD display... -
Page 4: Dimensional Drawing
F-2000 Page 4 Dimensional Drawing 3.25 in. 4.00 in. (82.55 mm) (101.6 mm) ® BLUE-WHITE INDUSTRIES F-2000 8888.8888 4.00 in. (101.6 mm) MA BATCH # RATE TOT AL SETPOINT ENTER CLEAR CLEAR SETPOINT TOTAL Flow Monitoring System Fig. 1 Temperature vs. Pressur Temperature 200°F (93.3°C) - Page 5 F-2000 Page 5 IPS PIPES MOLDED INLINE BODIES - Standard Flow Range #1 [Min - Max] Pipe Size GPM 1 GPH 1 GPD 1 LPM 1 LPH 1 M3H 1 3/8” .800 - 8.000 48.0 - 480.0 1100 - 11000 3.00 - 30.00...
-
Page 6: Mounting Options
F-2000 Page 6 Mounting Options Rotating Display Step 1: Remove Two Screws Step 2: Rotate 90° Step 3: Re-attach Screws Fig. 6 Angle Mount on Horizontal Pipe Recommended Vertical 45° Acceptable 45° Acceptable Fig. 7 Panel Mount .032 3.622 ±... - Page 7 F-2000 Page 7 Optional Pipe and Wall Mount Adapter Kit Screw Wall Wall Mount Mounting Display Base Module ® BLUE-WHITE INDUSTRIES F-2000 ENTER CLEAR CLEAR SETPOINT TOTAL Flow Monitoring System Wire to Wall Sensor Plug Screw Fig. 10 Clamp Pipe Mount...
-
Page 8: Electrical Wiring Connections
F-2000 Page 8 F-2000 Electrical Wiring Connections 6.1 Enclosure knock-out Instructions Option A: 1 / 2-14 MPT Red Cap Plug (for pipe fitting) Option A: Conduit Connection 1. Remove the red cap plug. 2. Install your pipe fitting (1/2 - 14 NPT male end). -
Page 9: Model Rt Circuit Board Wiring
Pulse input (bare wire from hall effect sensor) Open connector NPN positive (+) signal output pulse output NPN negative (-) signal output (from sensor) F-2000 RT Board Jumper Positions Backup Battery Connector F-2000 PC Board Jumper Not Jumper... -
Page 10: Model Fhxx And Fcxx Sensor Wiring
F-2000 Page 10 6.4 Model FHXX and FCXX Sensor wiring Input Supply Voltage (+ 6 to 24 Vdc) Signal Output (square wave) BARE Ground (-) BLACK Model FHXX Note: Output type - current sinking type hall effect sensor (13.5mA max). -
Page 11: Operation
Theory of Operation The MODEL RT is the base unit of the F-2000 flow monitoring system. Fluid flowing through the pipe causes the paddlewheel to spin. Pulses generated by the spinning paddlewheel are counted and multiplied by scaling factors. The resulting flow rate amounts and total flow amounts are displayed on the LCD readout. -
Page 12: Model Rt Features
TOTAL 7.2.3 How Do I Determine My Calibration Numbers? When ordered as a complete system, the F-2000 MODEL RT is factory programmed to the flow range you specified when you placed your order. See section 4.0 for various flow ranges. - Page 13 F-2000 Page 13 Step 1 Where would you like your displayed flow rate decimal point located? Desired Location D (Decimal Rate Factor) Note: Four decimal places maximum. XXXXX XXXX.X XXX.XX XX.XXX 1000 X.XXXX 10000 Enter your D here. Step 2...
- Page 14 F-2000 Page 14 Step 4 Calculate your Rate Scale Factor (S ) using the following formula. D from Step 1, Seconds from Step 2, K-Factor from Step 3. Example: x Seconds 10 x 3600 = 10 K-Factor 63.52 Seconds = 3600 K-Factor = 63.52...
-
Page 15: Programming The Model Rt
F-2000 Page 15 7.2.4 How Do I Program The MODEL RT? Note: While in the programming mode, if no buttons are pressed within twenty seconds, the programming mode is automatically exited without saving the input of the last screen. See page 18 for programming menu flow chart. -
Page 16: Calibration Constants
Note: The values in the following tables are based on laboratory testing of nominal pipe dimensions. The F-2000 sensor is factory calibrated to ±1% of full scale linearity. Your actual accuracy will vary based on your pipe I.D. And other installation factors. - Page 17 F-2000 Page 17 Low Flow Range #2 - GPM (gallons per minute) RATE 1 RATE 2 TOTAL 1 TOTAL 2 Pipe Size Flow Range K-Factor Rate Scale Rate Display Total Scale Total Display Pipe Sch. Body I.D. (In.) (in.) (GAL/Min)
-
Page 18: Programming Flow Chart
F-2000 Page 18 Programming Menu Flow Chart MODIFYING DESCRIPTION SCREEN 000000 ENTER RATE 1 - Rate Scale Factor CLEAR CLEAR SETPOINT TOTAL RATE 00000 ENTER RATE 2 - Rate Decimal Factor CLEAR TOTAL RATE ENTER RATE 3 - Battery Save Mode On / Off... -
Page 19: Maintenance
F-2000 Page 19 MAINTENANCE The F-2000 requires very little maintenance, however, some conditions will cause increased wear or possible damage to the unit. Periodically remove the sensor assembly from the pipe fitting and inspect the meter for signs of wear and obstructions. -
Page 20: F-2000 Parts List
Enclosure F-2000 sensor mount 76001-150 Enclosure F-2000 panel mount 90006-593 Gasket F-2000 1/4 DIN panel mount 90008-331 Cap plug P-48 1/2 NPT red F-2000 90006-594 Bracket F-2000 1/4 DIN panel mount 70000-500 Connector liquid-tight 1/2 in. 70000-589 Connector liquid-tight 3/4 in. -
Page 21: F-2000 Exploded View
F-2000 Page 21 F-2000 Exploded View H I T ® I N D I E S F l o O IN n i t i n g 11 11 s t e... - Page 22 Warranty ! Blue-White flowmeters are warranted to be free from defects in material and workmanship for 12 months from date of factory shipment. Warranty coverage is limited to repair or replacement of the defective flowmeter only. ! This warranty does not cover damage to the flowmeter that results from misuse or alterations, nor damage that occurs as a result of: meter misalignment, improper installation, over tightening, use of non-recommended chemicals, use of non-recommended pipe dopes or adhesives, excessive heat or pressure or allowing the meter to support the weight of related piping.
