CUCM Integration with Content Server 6.2
Step 4
Click Save.
Field
Pattern Definition
Route Pattern
Route Partition
Description
Numbering Plan
Route Filter
Cisco TelePresence Content Server Release 6.2.1 Administration and User Guide
3-28
Chapter 3 Configuring a Cisco Unified Communications Manager SIP Trunk with a Cisco TelePresence
Description
Enter the route pattern, including numbers and wildcards (do not use
spaces); for example, for NANP, enter 9.@ for typical local access, or
8XXX for a typical private network numbering plan. The uppercase
characters A, B, C, and D are valid characters.
Note
Ensure that the directory route pattern, which uses the chosen
partition, route filter, and numbering plan combination, is unique.
Check the route pattern, translation pattern, directory number, call
park number, call pickup number, message waiting on/off, or meet
me number if you receive an error that indicates duplicate entries.
You can also check the route plan report.
If you want to use a partition to restrict access to the route pattern, choose
the desired partition from the drop-down list box. If you do not want to
restrict access to the route pattern, choose <None> for the partition.
You can configure the number of partitions that display in this drop-down
list box by using the Max List Box Items enterprise parameter. If more
partitions exist than the Max List Box Items enterprise parameter specifies,
the Findbutton displays next to the drop-down list box. Click the Find
button to display the Find and List Partitions window. Find and choose a
partition name by using the Finding a Partition procedure in the Cisco
Unified Communications Manager Administration Guide.
Note
To set the maximum list box items, choose System > Enterprise
Parameters and choose CCMAdmin Parameters.
Note
Make sure that the combination of route pattern, route filter, and
partition is unique within the Cisco Unified Communications
Manager cluster.
Enter a description of the route pattern.
Choose a numbering plan
If your route pattern includes the @ wildcard, you may choose a route
filter. The optional act of choosing a route filter restricts certain number
patterns.
The route filters that display depend on the numbering plan that you
choose from the Numbering Plan drop-down list box.
You can configure the number of items that display in this drop-down list
box by using the Max List Box Items enterprise parameter. If more route
filters exist than the Max List Box Items enterprise parameter specifies, the
Find button displays next to the drop-down list box. Click the Find button
to display the Find and List Route Filters window.
