RS PRO RS-1360A Instruction Manual

Digital humidity/temperature meter
Hide thumbs

Advertisement

Quick Links

Download this manual
Instruction Manual
RS-1360A
Digital Humidity / Temperature Meter
EN
FR
IT
DE
TEMP = - 20 C ~ 60 C
HUMIDITY = 10 ~ 95 %RH
ES
°
°
- 4 F ~ 140 F
°
°
12/09/09 Version No. 00

Advertisement

loading
Need help?

Need help?

Do you have a question about the RS-1360A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RS PRO RS-1360A

Summary of Contents for RS PRO RS-1360A

  • Page 1 Instruction Manual RS-1360A Digital Humidity / Temperature Meter TEMP = - 20 C ~ 60 C ° ° - 4 F ~ 140 F ° ° HUMIDITY = 10 ~ 95 %RH 12/09/09 Version No. 00...

  • Page 3: Table Of Contents

    Digital Humidity / Temperature Meter / EN TABLE OF CONTENTS Title Page 1. SAFETY INFORMATION ........1 2. SPECIFICATIONS..........2 3. CONTROLS AND FUNCTIONS ......4 4. LCD DISPLAY DESCRIPTION ......6 5. MEASUREMENT ............ 7 6. BATTERY REPLACEMENT......... 13 08/15/16 Version No.

  • Page 4: Safety Information

    Digital Humidity / Temperature Meter / EN 1. SAFETY INFORMATION Read the following safety information carefully before attempting to operate or service the meter. Use the meter only as specified in this manual; otherwise, the protection provided by the meter may be impaired.

  • Page 5: Specifications

    Digital Humidity / Temperature Meter / EN 2. SPECIFICATIONS Measurement Range : Humidity : 10% to 95% RH Temperature : -20 to + 60℃, -4 to +140℉ Resolution : 0.1% RH, 0.1℃, 0.1℉ Accuracy : Humidity : ±3%RH ( at 30 to 95% RH ). ±5%RH ( at 10 to 30% RH ).
  • Page 6 Digital Humidity / Temperature Meter / EN Size : 270x68x25mm φ Humidity & Temp. sensor cap diameter: 20 Weight : Approx. 210g (including battery) Accessories : Instruction manual, Battery, Carrying case. 08/15/16 Version No. 01...

  • Page 7: Controls And Functions

    Digital Humidity / Temperature Meter / EN 3. CONTROLS AND FUNCTIONS TEMP = - 20 C ~ 60 C ° ° - 4 F ~ 140 F ° ° HUMIDITY = 10 ~ 95 %RH OPEN Humidity & Temp. sensor cap Display Power and data hold switch 08/15/16 Version No.
  • Page 8 Digital Humidity / Temperature Meter / EN ℃ / ℉ switch Main display (Temperature / %RH / Dew Point) on LCD switch. Manual recording key Manual recorded data reading key Battery cover 08/15/16 Version No. 01...

  • Page 9: Lcd Display Description

    Digital Humidity / Temperature Meter / EN 4. LCD DISPLAY DESCRIPTION 1. — :Negative sign 7. Measuring value (2 display) 8. %RH : Low-battery 9. ℃, ℉ M : Data recording 10. DEW : Dew point 4. R : Reading mode temperature 11.

  • Page 10: Measurement

    Digital Humidity / Temperature Meter / EN 5. MEASUREMENT 5-1 Temperature, humidity and dew point temperature measurement 1. Slide power switch to “ON” position. 2. Slide temperature units switch to desired ℃ or ℉ position. 3. Slide TEMP, %RH and DEW switch to desired position. (see below) Temperature : %RH :...
  • Page 11 Digital Humidity / Temperature Meter / EN DEW : 4. Slide power switch to “HOLD” position. Shows the “ HOLD ” symbol on the LCD. This is data holding mode. 5. “ ” symbol indicates that when there’s no operation on any switches / keys for 30 minutes from powering on, the meter will auto power off.
  • Page 12 Digital Humidity / Temperature Meter / EN Shows the “ M ” symbol on the LCD about 0.5 second. The number of memorized records increases by 1 to the maximum of readings of 99. When 99 sets, the “ M FULL” symbol will show on the LCD about 0.5 second.
  • Page 13 Digital Humidity / Temperature Meter / EN 2. To Recall and Read Manual Memorized Reading Press ”READ” key momentarily to read manual recorded data. The “ R ” symbol will show on the LCD to indicate you are in manual read mode. The LCD shows the data from the 34 record.
  • Page 14 Digital Humidity / Temperature Meter / EN To exit the reading mode Keep Pressing “READ” key for about 2 seconds. 3. To Clear the manual memorized data Turn off the meter then keep pressing “MEMORY” key and turn on the meter until “ M CLr ”...
  • Page 15 Digital Humidity / Temperature Meter / EN 5-4 User calibration procedure Use a standard calibrated humidity meter or humidity calibration capsules to verify the reading 1. Press and hold down “READ” and “MEMORY” key, then power until the LCD show the “CAL” symbol. 2.

  • Page 16: Battery Replacement

    Digital Humidity / Temperature Meter / EN 6. BATTERY REPLACEMENT 1. If battery power is not sufficient the LCD will display Replacement with one new battery, type 9V, is required. 2. Press battery cover and push in the direction of the arrow to open.
