Summary of Contents for Foxpro NX4

  • Page 2: Important Information

    General Inquiry E-mail: sales@gofoxpro.com Stay up to date with the latest sounds by visiting our online sound library. Watch for ® new products and upgrades from FOXPRO . Visit us online: www.gofoxpro.com This manual, the animal sounds stored in your caller, and animal sounds purchased from ®...

  • Page 3: Table Of Contents

    Batteries and Charging ................8 Using External Power Sources..............9 Programming the NX4 ................10 6-1 Getting New Sounds ................10 6-2 Programming the NX4 (Windows PC’s) ........... 10 6-3 Working with Sequences................. 12 Product Care & Maintenance..............14 Troubleshooting ..................15...

  • Page 4: Getting Started

    ® Congratulations on your purchase of the FOXPRO NX4 digital wildlife caller! In order to receive the maximum benefit of your NX4, please read the instruction manual in its entirety. WARNING: To avoid personal injury and product damage, read all operating instructions and safety precautions in this guide before using the ®...

  • Page 5: Nx4: Power Requirements

    After removing the door, locate the black plastic battery tray. The tray is double- sided, providing spaces for 8 ‘AA’ batteries. The tray is connected to a power cable inside of the NX4. You may unplug this cable and remove the tray from the caller during battery installation.

  • Page 6: Jukebox Mode (Version R7 Only)

    001, then 002, and so on. When the last sound is played through, it starts back at 000 and continues. To deactivate Jukebox Mode, turn off the NX4 and then it turn it back out without depressing the Sound Up arrow button.

  • Page 7: About The Speakers

    3-1 Using External Speakers The NX4 is equipped with two external speaker jacks, which allows you to connect up to two additional speakers. The internal speakers perform admirably, however, you may encounter situations that require higher volume levels. By connecting a larger and more efficient external speaker(s) to the NX4, the volume level can be increased greatly.

  • Page 8: Batteries And Charging

    If the batteries drop too low to power the NX4, it will shut itself off. Battery run time is directly related to how loud you operate the NX4. Using both speakers at the same time rather than only the most appropriate one will have a negative impact on run time.

  • Page 9: Using External Power Sources

    Unlike some older FOXPRO game calls, you cannot connect an external power source to the charge jack on the NX4. An external power source can only be connected through the back of ® the unit where the battery tray connects. FOXPRO offers a replacement door for the NX4 that is fitted with the appropriate jack for connecting an external power supply.

  • Page 10: Programming The Nx4

    6. Programming the NX4 Programming your NX4 can be done from home with the use of a PC or Mac computer, or by sending the NX4 to the factory. In order to program the NX4 from home, you will need the...
  • Page 11 Connecting your NX4 to the PC You can now connect the NX4 to your PC. The USB port is located inside the battery compartment. You will need to obtain the appropriate USB cable (USB 2.0 printer-style cable) as one is not included with the product.

  • Page 12: Working With Sequences

    The NX4 features the ability to operate from a special sequence file for sound playback. A sequence file is a text based file that contains unique instructions to guide your NX4 through a stand. These instructions include commands to play a particular sound a certain number of times, enter a passage of silence, and so forth.
  • Page 13 ; Quit the sequence IMPORTANT NOTE When using a sequence file, you must be sure that the NX4 has a maximum of 75 sounds installed. If you have more than 75 sounds installed and then try to operate from a sequence file, the NX4 will ignore the sequence file entirely. The NX4 has a 200 sound capacity, but can only hold 75 when using a sequence.

  • Page 14: Product Care & Maintenance

    7. Product Care & Maintenance ® In order to help get years of trouble free service with your FOXPRO game call, it is strongly recommended that you read and understand the following points. Many of these are considered proactive or preventative.

  • Page 15: Troubleshooting

    The most common problems are battery related. Before performing anything else, try installing fresh batteries. When your batteries get low in the NX4, unexpected operation can occur. You can experience such things as loss of audio quality and other abnormal operation.

  • Page 16: Warranty Statement

    Online Warranty Registration You can register your NX4 digital game call online at the following address (locate the Warranty Registration link on the left of this page): http://www.gofoxpro.com/warranty Make sure that you retain a hard copy of your proof of purchase (i.e.
