Magnum CARIMIG 202LCD Manual

Multi-process dc lcd welder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Our Customer Service staff are ready to provide assistance.
If a part is damaged or missing, replacement parts can be
shipped from our facility.
For help with assembly, or for additional product
information, call our North American toll-free number:
1-800-567-8979
You will need this manual for safety instructions, operating procedures, and warranty.
Put it and the original sales invoice in a safe, dry place for future reference.
Vous aurez besoin de ce guide pour les instructions de sécurité, les procédures d'utilisation et la garantie.
Multi-Process DC LCD Welder
QUESTIONS? 1-800-567-8979
SAVE THIS MANUAL
CONSERVEZ CE GUIDE
Conservez-le dans un endroit sûr et sec pour référence future.
Model
Notre personnel de service à la clientèle sera prêt à
fournir assistance. Si une pièce est endommagée ou
manquante, des remplacements seront expédiés de notre
usine.
Pour de l'aide avec l'assemblage, ou pour des
informations additionnelles sur le produit, appeller notre
numéro sans frais nord-américain : 1-800-567-8979
CARIMIG 202LCD
:
WE3107 v.110413

Advertisement

Table of Contents
loading

Related Manuals for Magnum CARIMIG 202LCD

Summary of Contents for Magnum CARIMIG 202LCD

  • Page 1 CARIMIG 202LCD Model Multi-Process DC LCD Welder QUESTIONS? 1-800-567-8979 Our Customer Service staff are ready to provide assistance. Notre personnel de service à la clientèle sera prêt à If a part is damaged or missing, replacement parts can be fournir assistance. Si une pièce est endommagée ou shipped from our facility.
  • Page 2 Operating Instructions and Parts Manual Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property.
  • Page 3 GENERAL SAFETY INSTRUCTION -Wear proper gloves and protective clothing to prevent your skin from being exposed to hot metals, UV and IR rays. -Do not overuse or overheat your welder. Allow proper cooling time between duty cycles. -Keep hands and fingers away from moving parts and stay away from the drive rolls.
  • Page 4 GENERAL SAFETY INSTRUCTION UV and IR Arc Rays The welding arc produces ultraviolet (UV) and infrared (IR) rays that can cause injury to your eyes and skin. Do not look at the welding arc without proper eye protection. -Always use a helmet that covers your full face from the neck to top of head and to the back of each ear.
  • Page 5 GENERAL SAFETY INSTRUCTION Sparks/Flying Debris Welding creates hot sparks that can cause injury. Chipping slag off welds creates flying debris. -Wear protective apparel at all times: ANSI-approved safety glasses or shield, welder’s hat and ear plugs to keep sparks out of ears and hair. Electromagnetic Field -Electromagnetic fields can interfere with various electrical and electronic devices such as pacemakers.
  • Page 6 Operating Instructions and Parts Manual Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. Please retain instructions for future reference.
  • Page 7 MIG/MMA WELDER Operating Instructions and Parts Manual 1.3 After unpacking unit, inspect carefully for any damage that may have occurred during transit. Check for loose, missing, or damaged parts. Shipping damage claim must be filed with carrier. Operating Instructions and Parts Manual Specifications and Dimension Description Specification...
  • Page 8 MIG/MMA WELDER Operating Instructions and Parts Manual Removing from carton 1.1 Remove cartons, bags or Styrofoam containing the welder and accessories. 1.2 Check the contents with the packing list below. Factory standard：EN60974-1 Optional accessories：Protective mask、tip、welding wire Know your Welder Front Ctrl Panel MIG Socket Torch Polarity Change Cable...
  • Page 9 MIG/MMA WELDER Operating Instructions and Parts Manual INPUT POWER CORD The power cord connects the welder to the 120V/230 volt power supply. 14 amp receptacle to supply power to the welder. Torch Polarity Change Cable To change the polarity of gun for kinds of core wire welding. NAMEPALTE OF WELDER The nameplate indicate the main electrical data of welder.
  • Page 10 MIG/MMA WELDER Operating Instructions and Parts Manual Interface description 1. Multi-functions selection: Total 9 functions, 8 welding functions and 1 setting. Adjusting multi-function knob for selecting, press for confirming 2. Output setup: Shows output connection under different welding mode, press multi-function knob for confirming 3.
  • Page 11 MIG/MMA WELDER Operating Instructions and Parts Manual 4. Material thickness: Adjusting multi-function knob to select different material thickness, press for confirming 5. Welding display：Shows all selected parameters. a. Under MIG welding, user can set wire feeding speed and voltage. Adjusting Multi-function knob to set electro-inductance, press the knob to progress basic parameter setting.
  • Page 12 MIG/MMA WELDER Operating Instructions and Parts Manual c. Under Stick welding, user can set current, arc force parameter and hot start. 6. Setting interface: It shows language setting, units setting, light setting, information and recover setting. 7. Alarm interface:It shows the machine is overloaded and the internal temperature is too high.
  • Page 13 MIG/MMA WELDER Operating Instructions and Parts Manual Installation Outside Connection of the Machine 1. Power requirement AC single phase 230V or 120V , 50/60HZ fused with a 15 amp time delayed fuse or circuit breaker is required. •High voltage danger from power source! Consult a qualified electrician for proper installation of receptacle.
  • Page 14 MIG/MMA WELDER Operating Instructions and Parts Manual drop they produce. This drop in voltage can affect the performance of the welder. If you need to use an extension cord it must be a #12 gauge cord at the smallest. -Do not use an extension cord over 25 ft. in length. 3.
  • Page 15 MIG/MMA WELDER Operating Instructions and Parts Manual 4. Ground clamp connection Clear any dirt, rust, scale, oil or paint on the ground clamp. Make certain you have a good solid ground connection. A poor connection at the ground clamp will waste power and heat.
  • Page 16 MIG/MMA WELDER Operating Instructions and Parts Manual -Do not touch cylinder with MIG gun. -Do not weld on the cylinder. -Always secure cylinder upright to a cart or stationary object. -Keep cylinders away from welding or electrical circuits. -Use the proper regulators, gas hose and fittings for the specific application. When MIG (solid) wires are used, the shielding gas is required.
  • Page 17 MIG/MMA WELDER Operating Instructions and Parts Manual 6.2.The gas hose, regulator and gas cylinder connection Attach one end of the gas hose to the gas solenoid valve (gas inlet) located on the back panel of the welder. Attach the other end to the gas regulator which is attached to the shielding gas cylinder.
  • Page 18 MIG/MMA WELDER Operating Instructions and Parts Manual 7 Installation of Wire Spool 7.1 Open the turning plate of the machine, rotate the adjusting nut on the wire shaft anti- clockwise to remove it from the wire spool screw, and then take down the wire spool block seat;...
  • Page 19 MIG/MMA WELDER Operating Instructions and Parts Manual Installation of wire feeder and connection of welding stick 8.1 While installing the wire spool, check previously that wire feeding roller in the wire feeder is suitable for the contact tip in the torch and wire diameter 8.2 After the confirmation or the replacement of the wire feeding roller and contact tip, put the press roller adjusting to the machine behind.
  • Page 20 MIG/MMA WELDER Operating Instructions and Parts Manual 9.4 after the installation of wire roller, screw the cover clockwise tightly. Make sure the screw thread connection is correct, to avoid damaging of the screw thread due to the connection deviation. Remark: he spec marked on the front of the roller is the size of roller groove in the back of the roller.
  • Page 21 MIG/MMA WELDER Operating Instructions and Parts Manual 3.1. Angle A can be varied, but in most cases the optimum angle will be 60 degrees, the point at which the torch handle is parallel to the work piece. If angle A is increased, penetration will increase.

  • Page 22: Welding Techniques

    MIG/MMA WELDER Operating Instructions and Parts Manual 5.4. With your free hand, turn the Wire Speed Dial to maximum and continue to hold onto the knob. 5.5. Lower your welding helmet and pull the trigger on the torch to start an arc, then begin to drag the torch toward you while simultaneously turning the Wire Speed Dial counter- clockwise.
  • Page 23 MIG/MMA WELDER Operating Instructions and Parts Manual The STRINGER BEAD Is formed by traveling with the torch in a straight line while keeping the wire and nozzle centered over the weld joint (See following figure) The WEAVE BEAD Is used when you want to deposit metal over a wider space than would be possible with a stringer bead.
  • Page 24 MIG/MMA WELDER Operating Instructions and Parts Manual puddle control and allow slower rates of travel speed to achieve deeper penetration. When vertical welding, angle B (see HOLDING THE TORCH) is usually always kept at zero, but angle A will generally range from 45 to 60 degrees to provide better puddle control. OVERHEAD POSITION Is the most difficult welding position.
  • Page 25 MIG/MMA WELDER Operating Instructions and Parts Manual Fillet Weld Joints. Most fillet weld joints, on metals of moderate to heavy thickness, will require multiple pass welds to produce strong joint. The illustrations in Figure 19 show the sequence of laying multiple pass beads into a T fillet joint and a lap fillet joint. 6.5 Spot welding There are three methods of spot welding: Burn-Through, Punch and Fill, and Lap.
  • Page 26 MIG/MMA WELDER Operating Instructions and Parts Manual 6.6 SPOT WELDING INSTRUCTIONS 1. Select the wire diameter and heat setting recommended above for the method of spot welding you intend to use. 2. Tune in the wire speed as if you were going to make a continuous weld. 3.
  • Page 27 MIG/MMA WELDER Operating Instructions and Parts Manual a. The bead will be high and irregular b. The arc will be difficult to maintain 3. When the rod is too large a. The arc will burn through light metals b. The bead will undercut the work c.
  • Page 28 MIG/MMA WELDER Operating Instructions and Parts Manual 2.2 Striking the arc EXPOSURE TO A WELDING ARC IS EXTREMELY HARMFUL TO THE EYES AND SKIN. •Never strike an arc or begin welding until you have adequate protection. • Wear flameproof welding gloves, heavy long-sleeved shirt, cuffless trousers, high-topped shoes and a welding helmet or shield.
  • Page 29 MIG/MMA WELDER Operating Instructions and Parts Manual 2.3 Types of weld bead The following paragraphs discuss the most commonly used arc welding beads. The stringer bead Formed by traveling with the electrode in a straight line while keeping it centered over the weld joint. The weave bead Used when you want to deposit metal over a wider space than would be possible with a stringer bead.
  • Page 30 MIG/MMA WELDER Operating Instructions and Parts Manual The horizontal positionis is performed very much the same as the flat weld except that the angle is different such that the electrode, and therefore the arc force, is directed more toward the metal above the weld joint. This more direct angle helps prevent the weld puddle from running downward while still allowing slow enough travel speed to achieve good penetration.
  • Page 31 MIG/MMA WELDER Operating Instructions and Parts Manual A solid weld bead requires that the electrode be moved slowly and steadily along the weld seam. Moving the electrode rapidly or erratically will prevent proper fusion or create a lumpy, uneven bead. To prevent ELECTRIC SHOCK, do not perform any welding while standing, kneeling, or lying directly on the grounded work.
  • Page 32 MIG/MMA WELDER Operating Instructions and Parts Manual Striking the arc method following step: A.Turns on the welding torch built-in air valve Approaches the striking the arc spot the spray nozzle to cause the tungstic electrode and the work piece is separated 2~3mm B.Slowly lifts the welding torch to cause the tungstic electrode contact work piece C.Lifts the welding torch to the normal position, starts to weld...
  • Page 33 MIG/MMA WELDER Operating Instructions and Parts Manual Trouble shooting Chart Breakdown Analysis Solutions Voltage is too high Switch off power source; Check (≥15%) the main supply; Restart welder when power recovers to normal Voltage is too low state. (≤15%) Bad power Improve the ventilation condition.
  • Page 34 MIG/MMA WELDER Operating Instructions and Parts Manual Too large contact tip Change the proper contact tip or makes the current roller unsteady Too thin power cable Change the power cable Arc is not makes the power stable and splash is astaticism large Too low input voltage...
  • Page 35 MIG/MMA WELDER Operating Instructions and Parts Manual Main Circuit chart + 15V -15V IF B G N D...
  • Page 36 MIG/MMA WELDER Operating Instructions and Parts Manual Spare Part List Repair Parts List Serial number Code Definition Quantity 2.05.08.115 Holder 2.05.17.012 Hinge 1.1.01.01.0890 Case 1.1.01.05.3233 Riser 1.2.02.01.6569 Backboard 2.03.05.275 Power line 2.04.30.102 Fixed head of cable 2.07.55.021 Gas valve 2.07.80.001 Power switch 2.07.89.057 2.02.02.044...
  • Page 37 MIG/MMA WELDER Operating Instructions and Parts Manual 1.1.01.04.1537 Baseboard 2.05.05.519 Front plastic board 2.07.57.960 Rapid socket 2.07.54.019 Aerial socket 1.2.07.02.3975 Umpolung cable 2.07.11.021 Potentiometer knob 1.1.05.07.0268 Panel support plate 1.1.05.07.0268 LCD control panel 1.1.02.01.9637 Fixed plate of wire feeder 1.1.02.01.9636 Subplate of wire feeder 2.20.02.261 Central socket...
