Evaluation Board User Guide
Item Qty Reference Designator
52 7 MP101, MP102, MP103, MP104, MP105,
MP106, MP107
53 4 MP111, MP112, MP113, MP114
Description
Part of assembly, 100 mil
jumpers, place into P100
(Pin 2 to Pin 3), P200 (Pin 1
to Pin 2), J300 (Pin 3 to
Pin 4), P600 (Pin 1 to Pin 2,
Pin 3 to Pin 4, Pin 5 to Pin 6,
Pin 7 to Pin 8)
Part of assembly, insert/
snap into the large holes
from the bottom side of
board, 14 mm height, dual
locking standoffs for circuit
board support
Rev. 0 | Page 27 of 28
Manufacturer Part Number
SAMTEC SNT-100-BK-G-H
RICHCO CBSB-14-01
UG-200
