UG-200
Item Qty Reference Designator
24 2 R117, R118
25 2 R119, R120
26 2 R206, R207
27 4 R105, R106, R111, R112
28 5 R200, R201, R600, R601, R602
29 2 R127, R128
30 6 R204, R205, R303, R307, R308, R700
31 10 R300, R304, R305, R306, R309, R603, R604,
R605, R701, R702
32 1 R704
33 1 R703
34 1 R301
35 1 R302
36 1 R316
37 2 R103, R130
38 2 R311, R313
39 2 T101, T104
40 2 T103, T200
41 1 T105
42 1 DUT1
43 1 U100
44 1 U300
45 1 U400
46 1 U600
47 1 U601
48 2 U700, U701
49 1 U702
50 1 U703
51 1 Y200
Description
Resistor, 5.60 Ω, 1/16 W, 1%,
0402, SMD
Resistor, 15 Ω, 1/20 W, 5%,
0201, SMD
Resistor, 33 Ω, 1/10 W, 5%,
0402, SMD
Resistor, 33 Ω, 1/10 W, 5%,
0402, SMD
Resistor, 10.0 kΩ, 0402,
1/16 W, 1%
Resistor, 0.0 Ω, 1/20 W, 0201,
SMD
Resistor, 249 Ω, 0402,
1/16 W, 1%
Resistor, 1.00 kΩ, 0402,
1/16 W, 1%
Resistor, 750 Ω, 1/10 W, 5%,
0402, SMD
Resistor, 316 Ω, 0402,
1/16 W, 1%
Resistor, 4.12 kΩ, 0402,
1/10 W, 1%
Resistor, 5.1 kΩ, 0402,
1/16 W, 5%
Resistor, 200 Ω, 1/10 W, 1%,
0402, SMD
Resistor, 20 Ω, 1/20 W, 5%,
0201, SMD
Resistor, 100 Ω, 1/10 W, 5%,
0402, SMD
XFMR, 1:1 impedance ratio
Balun, 1:1 impedance ratio
Balun, 1:1 impedance ratio
IC-ADI LFCSP 10 mm ×
10 mm plus EPAD
IC 2.6 GHz ultralow
distortion differential IF/RF
amplifier
IC-ADI 12-output CLK GEN
with INT 1.6 GHZ VCO
IC, voltage ref, precision
series, SOT23_6
IC tinylogic UHS dual buffer
IC tinylogic UHS dual buffer
IC, regulator 0.8 V to 5.0 V,
low dropout CMOS, SO8
IC-ADI low dropout CMOS
linear regulator
IC-ADI low dropout CMOS
linear regulator
250 MHz, XTAL 3.3 V LVPECL
OSC
Rev. 0 | Page 26 of 28
Evaluation Board User Guide
Manufacturer Part Number
Vishay/Dale CRCW04025R60FNED
Panasonic ERJ-1GEJ150C
Panasonic ERJ-2GEJ330X
Panasonic ERJ-2GEJ330X
Panasonic ERJ-2RKF1002X
Panasonic ERJ-1GE0R00C
Panasonic ERJ-2RKF2490X
Panasonic ERJ-2RKF1001X
Panasonic ERJ-2GEJ751X
Panasonic ERJ-2RKF3160X
Panasonic ERJ-2RKF4121X
Panasonic ERJ-2GEJ512X
Panasonic ERJ-2RKF2000X
Panasonic ERJ-1GEJ200C
Panasonic ERJ-2GEJ101X
Minicircuits ADT1-1WT+
Macom MABA-007159-000000
Anaren BD0205F5050A00
Analog Devices AD9467BCPZ-250
Analog Devices ADL5562ACPZ-R7
Analog Devices AD9517-4BCPZ
Analog Devices ADR130AUJZ
Fairchild NC7WZ07P6X
Fairchild NC7WZ16P6X
Analog Devices ADP1708ARDZ-R7
Analog Devices ADP1706ARDZ-3.3-R7
Analog Devices ADP1706ARDZ-1.8-R7
Vectron VCC6-QCD-250M000
