Aaeon EMB-Q77A Owner's Manual page 7

Chipset
Resolution
Output interface
Storage
Serial port
USB
Fan
RTC
Keyboard/Mouse
Audio
Ethernet
Display
Others
Chapter 1: General information
DISPLAY
Intel Graphics Media Accelerator
®
Up to 1920x1200@60Hz for DVI-D
Up to 1920x1200@60Hz for DVI-I
1 x DVI-D
1 x DVI-I
I/O
2 x SATA 6.0Gb/s ports
2 x SATA 3.0Gb/s ports
RAID 0 / 1 / 5 / 10
1 x RS-232/422/485 supports 5V/12V/RI option (COM1, box header)
1 x RS-232 (COM2, box header)
4 x USB3.0 (2 ports at mid-board, 2 ports at rear panel)
8 x USB2.0 (2 ports at mid-board, 6 ports at rear panel)
1 x CPU Fan connector (4-pin)
1 x Chassis Fan connector (4-pin)
Internal RTC
1 x PS/2 Keyboard / mouse port on rear I/O
Realtek ALC887,Mic-in/Line-in/ Line-out
1 x Internal speaker connector
1 x Front panel audio connector (supports AAFP)
2 x RJ-45 ports on rear I/O
1 x DV-D port on rear I/O
1 x DVI-I port on rear I/O
1 x Front panel connector (Pin header)
1 x Chassis intrusion
1-3
