Chapter 1
Product overview
1.1

Package contents

Check your industrial motherboard package for the following items.
1 x Industrial Motherboard
1 x SATA Cable
1 x I/O Shield
1 x Support CD
If any of the above items is damaged or missing, contact your distributor or
sales representative immediately.
1.2

Features

• Intel Socket 1155 for 3
®
Pentium / Celeron
®
• Two 240-pin Dual Channel DDR3 1600/1333/1066MHz DIMMs up to 16GB
• SATA 6.0 Gb/s x 2, SATA 3.0 Gb/s x 2 (supports RAID 0/1/5/10), USB3.0 x 4,
USB2.0 x 8, COM x 2
• PCI-Express[x16] x 1, Mini Card (USB+PCIe) Half size x 1
• EuP/ErP Compliance
Chapter 1: General information
/2 Generation Core™ i7/Core™ i5 / Core™ i3 /
nd nd
Processors up to 95W
®
1-1
