Aaeon EMB-Q77A Owner's Manual page 11

Connectors/Jumpers/Slots
1. CPU and system fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN)
2.
USB 3.0 connector (20-1 pin USB3_34)
3. Serial ATA 3.0Gb/s connectors (7-pin SATA3G_1, SATA3G_2)
4.
USB 2.0 connector (10-1 pin USB1112)
5. Clear RTC RAM (CLRTC)
6. Chassis intrusion connector (4-1 pin CHASSIS)
7. Serial port connectors (10-1 pin COM1, 10-1 COM2)
8. DIMM memory slots
9. ATX power connectors (24-pin EATXPWR, 4-pin EATX12V)
10. Intel
ME Jumper (3-pin DIS_ME)
®
11. Speaker connector (4-pin SPEAKER)
12. System panel connector (10-1 pin F_PANEL)
13. Standby Power LED (SB_PWR LED)
Intel LGA1155 CPU socket
14.
®
15. Front panel audio connector (10-1 pin AAFP)
16. Internal monophonic speaker connector (2-pin INT_SPKR1)
17. COM1 Ring/+5V/+12V selection (COM1_VSET)
18. Serial ATA 6.0Gb/s connectors (7-pin SATA6G_1, SATA6G_2)
Chapter 2: Motherboard information
Page
2-20
2-24
2-23
2-24
2-13
2-21
2-25
2-11
2-19
2-14
2-26
2-22
2-15
2-6
2-21
2-26
2-14
2-23
2-3
