PARTS LIST

Ref. No. Description

Model 6 Geiger Counter

UNIT Completely Assembled
Model 6 Geiger Counter

Circuit Board, Drawing 363 X 452

BOARD Assembled Circuit
CAPACITORS
C1-C4 100μF, 10V, DT
C5 1μF, 35V, DT
C6-C8 10μF, 20V, DT
C9 1μF, 35V, DT
C10 330pF, 100V
C11-C12 0.001μF, 100V, C
C13 470pF, 100V
C14 0.1μF, 100V, C
C15 0.01μF, 100V, C
C16 0.0027μF, 3kV, C
C17-C18 0.0015μF, 3kV, C
C19-C20 100pF, 3kV, C
C21 0.0047μF, 100V, C
TRANSISTORS
Q1-Q3 2N3904
Q4 2N4402BU
Q5 2N4402
INTEGRATED CIRCUITS
U1 CA3096
U2 MAX631
U3 ICM7555
U4 TLC27M7IP
U5 TLC372
U6 LM385Z-1.2
DIODES
CR1 1N4148
CR2-CR3 1N4007
THERMISTORS
R37-R38 RL1006-98
Model 6 Geiger Counter
February 2011
Part No. Ref. No.
RESISTORS
R1-R2
R3
48-1676
R4
R5
R6
R7
5363-610
R8
R9
R10
R11
04-5576
R12
04-5575
R13
04-5592
R14
04-5575
R15
04-5531
R16
04-5519
R17
04-5555
R18
04-5521
R19
04-5523
R20
04-5520
R21
04-5518
R22
04-5532
R23
04-5570
R24
R25
R26
R27
05-5755
R28
05-5763
R29-R30
05-5775
R31
R32
R33
R34 - R35
06-6023
R36
06-6249
06-6136
INDUCTOR
06-6248
06-6265
L1
05-5808
TRANSFORMERS
T1
07-6272
07-6274
DETECTORS
V1
07-6332
page 4
Description Part No.
10k 10-7016
2.2k 10-7012
1 MEG 10-7028
10k 10-7016
SAT (2.37k TYP.) 12-7648
1k 10-7009
47k 10-7020
10k 10-7016
1 MEG 10-7028
330k 10-7051
10k 10-7016
200 OHM 10-7006
220k 10-7066
18k 10-7018
82k 10-7022
33k 10-7019
10k 10-7016
1k 10-7009
100k 10-7023
180k 10-7068
100k 10-7023
10 MEG 10-7031
4.7k 10-7014
1.5 MEG 10-7038
2.2 MEG 10-7052
22k 10-7070
100 OHM 10-7004
100k 10-7023
1 G 12-7686
634R, 1/3W, 1% 12-7808
100k TRIMMER 09-6823
1 MEG TRIMMER 09-6828
100k TRIMMER 09-6823
470UHY
L8050
GM TUBE-LND 71412
21-9600
40-0902
