Wiring Diagram, Drawing 363 X 466 - LUDLUM Model 6 Manual

Ref. No. Description
MISCELLANEOUS
P2 CONN-640456-9
MTA100
7 EA. CLOVERLEAF
011-6809-000-599

Wiring Diagram, Drawing 363 x 466

CONNECTORS
J1 CONN-640442-9
MTA100
SWITCHES
S1 D3G0402N
BATTERY
B1-B2 DURACELL "D"
Model 6 Geiger Counter
February 2011
Ref. No.
Part No.
MISCELLANEOUS
M1
13-8094
*
*
18-8771
*
*
*
*
*
13-8169
*
*
08-6501
*
21-9313
page 5
Description Part No.
PORT BEZEL
W/MOVEMENT 4363-188
PORT BEZEL
W/GLASS 4363-352
PORT METERFACE 7363-136
METER MOVEMENT 15-8030
PORTABLE KNOB 08-6613
MAIN HARNESS
Model 6 8363-622
BATTERY CONTACT SET
CASTING SCREENED
Model 6 9363-324
CAN ASSY.
Model 6 4363-321
BATT LID W/LATCHSET
Model 6 9363-325
PORT HANDLE (ROLLED)
W/SCREWS 7363-139
