IntelliFire™ Touch Remote Control & Auxiliary Control Module
Leave this manual with party responsible for use
and operation.
1. Introduction
The IntelliFire™ Touch Remote Control (IFT-RC400) is
a hand-held wireless device that is designed to control
the functions of Hearth & Home Technologies products
equipped with IntelliFire™Touch technology.
used to control the flame ON/OFF, flame height, cold cli-
mate and programmable timer functions of a appliance.
The IFT-RC400 is also equipped with a temperature sen-
sor which allows it's use as a thermostat to set the desired
room temperature.
The IntelliFire™ Touch auxiliary control module (IFT-
ACM) is included. The ACM is an AC powered device
that controls peripheral devices such as lights, fans and
Power Vents approved for use in Hearth & Home Technol-
ogies products that are equipped with IntelliFire™ Touch
technology. It is connected to and controlled by the Intel-
liFire™ Touch Electronic Control Module (IFT-ECM).
2. IFT-RC400 & ACM Installation
A. Precautions
This device is tested and safe when installed in accor-
dance with this installation manual. Do not install any
components that may be damaged.
Do not modify, disassemble, or substitute any of the com-
ponents included with this kit. Installation of this unit must
be done by a qualified service technician.
The location of this device may affect performance. An
assessment of the location should be done prior to instal-
lation for optimum performance.
Hearth & Home Technologies disclaims any responsibility
for, and the warranty will be voided by, the following actions:
• Installation and use of any damaged system component.
• Modification of the system component.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installation and/or use of any component part not approved
by Hearth & Home Technologies.
Any such action may cause a fire hazard.
• Read, understand and follow these instructions for safe
installation and operation.
1
Hearth & Home Technologies • IFT-RC400 & IFT-ACM Installation Instructions • 2326-982 Rev. F • 8/17
IFT-RC400 & IFT-ACM
Installation Instructions
B. Determine Location
Determine the location for the IFT-RC400. The selected
location should be in the same space as the gas appliance
with visual sight of the fireplace. The device must be placed
within 30 feet (9.14 m) of the appliance, but should not
be exposed to extreme heat. The IFT-RC400 is approved
for interior installation and should not be used in exterior
applications.
It can be
• Keep remote control out of reach of children.
C. Kit Contents
• IFT-RC400 Remote Control
• Radio Frequency Module (IFT-RFM)
• AAA Batteries (4)
• Wall Mount
• 1 inch #6 Screws (2)
• Drywall Anchors (2)
• IntelliFire™ Touch Auxiliary Control Module (IFT-ACM)
• Power cable that connects AC receptacle to IFT-ACM
• 1 inch sq. Piece of Velcro
D. Installation Steps
CAUTION! Do not install damaged components. If you
received components that are damaged, contact your
dealer for assistance.
1. Remove the contents from the packaging.
2. Locate the IntelliFire™ Touch electronic control mod-
ule (IFT-ECM) in the control cavity of the appliance
and move the three-position switch to the OFF posi-
tion. See Figure 1.
3. Connect the IFT-RFM to the IFT-ECM by aligning the
pins and tabs and pushing the IFT-RFM into the IFT-
ECM until both tabs snap into position. Ensure the two
components are fastened securely to one another.
See Figure 1.
