Introduction
This user guide serves as a quick reference to the screen,
functions and indicators on your IntelliFire™ Touch
Remote control.
SCREEN
INDICATOR BAR
ROOM TEMPERATURE
FUNCTIONS
DYNAMIC ICONS
IFT-RC400
IntelliFire™ Touch Remote Control
DISPLAY
SELECTION
INDEX
Hearth & Home Technologies • IFT-RC400 User Guide • 2326-983 Rev. C • 1/17
User Guide
Turn Flame On/Off
Toggle this function to turn ON or OFF your appliance.
Thermostat
You can set and maintain your desired room temperature
with the thermostat function. This function automatically
adjusts your appliance to maintain the desired set
temperature (ST).
To achieve the most accurate thermostat function, place
your remote control in the same general space that
you want to have the temperature controlled by your
appliance.
For
control away from direct radiant heat from the appliance,
adjacent windows and doors, HVAC vents, and direct
sunlight.
To use the thermostat function, access the main menu
screen on your remote, and select thermostat. Next,
simply select your desired set temperature by using the
arrow keys and press ON to confirm the setting. The
actual room temperature (RT), measured by your remote
control, will be displayed in the upper right corner of the
main menu screen. To turn the thermostat function off,
simply select thermostat on the main menu screen and
select OFF.
If the RT cools to more than 3 °F lower than the ST for
at least 2 minutes, then your appliance will automatically
turn ON. The thermostat function will automatically adjust
the flame height based on the difference between the RT
and the ST. As the RT rises closer to the ST, the flame
height will automatically adjust down. If the RT rises 2 °F
above the ST for at least 2 minutes, then your appliance
will automatically turn OFF.
During thermostat use, you will not be able to set your
desired flame height level. Your appliance will
automatically adjust flame height based on the difference
between the RT and ST.
Flame Height
You can set your desired flame height level to affect the
ambiance and control the heat output.
Your appliance will remember the previous flame height
setting and adjust the flame to that level 10 seconds after
start.
FUNCTIONS
best
results,
keep
your
remote
1
Advertisement
Table of Contents
Related Manuals for Hearth & Home IFT-RC400
Summary of Contents for Hearth & Home IFT-RC400
-
Page 1: User Guide
Your appliance will remember the previous flame height setting and adjust the flame to that level 10 seconds after start. Hearth & Home Technologies • IFT-RC400 User Guide • 2326-983 Rev. C • 1/17... -
Page 2: Child Lock
When the flame is turned off, a post-purge time of approximately 20 minutes will occur. Cold-climate function and battery backup are disabled if * = Optional Feature a Power Vent is used. Hearth & Home Technologies • IFT-RC400 User Guide • 2326-983 Rev. C • 1/17... - Page 3 3. Double-beep from the remote will indicate that the remote will reset the 300-hour maintenance reminder. If the remote 300-hour maintenance message does not clear on the first try, repeat above steps. Hearth & Home Technologies • IFT-RC400 User Guide • 2326-983 Rev. C • 1/17...
- Page 4 Verify home circuit breaker is on and master reset is on (if No power to appliance. message on-screen: equipped). “Remote Control Communication Power outage. Install new batteries in battery backup. Error.” Hearth & Home Technologies • IFT-RC400 User Guide • 2326-983 Rev. C • 1/17...
- Page 5 2) This device may accept any interference, including interfer- Hearth & Home Technologies dealer, ence that may cause undesired operation of the device. please visit www.hearthnhome.com. Hearth & Home Technologies • IFT-RC400 User Guide • 2326-983 Rev. C • 1/17...
