Leave this manual with party responsible for use
and operation.
1. Introduction
The IntelliFire Touch Remote Control (IFT2-RC450) is a
hand-held wireless remote that is designed to control the
functions of Hearth & Home Technologies (HHT) products
equipped with IntelliFire Touch
used to control the flame ON/OFF, flame height, cold cli-
mate and programmable timer functions of an appliance.
The RC450 is also equipped with a temperature sensor
which allows its use as a thermostat to set the desired
room temperature.
2. Installation
A. Precautions
The IFT2-RC450 is tested and safe when installed in ac-
cordance with this installation manual.
• DO NOT modify, disassemble, or substitute any of
the components included with this remote.
• Installation of this remote MUST BE DONE by a
qualified service technician.
• The remote control must be placed within 30 feet
(9.14 m) of the appliance, but should not be exposed
to extreme heat. The RC450 is approved for interior
installation and should not be used in exterior
applications.
NOTICE! Keep remote control out of reach of children.
Hearth & Home Technologies disclaims any responsibility
for, and the warranty will be voided by, the following actions:
• Installation and use of any damaged system component.
• Modification of the system component.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installation and/or use of any component part not approved
by Hearth & Home Technologies.
Any such action may cause a fire hazard.
• Read, understand and follow these instructions for safe
installation and operation.
1
Hearth & Home Technologies • IFT2-RC450 Installation Instructions • 2564-981 • 5/23
IFT2-RC450
IntelliFire Touch
Installation Instructions
technology. It can be
®
2.0 Remote Control
®
B. Kit Contents
• IFT2-RC450 Remote Control
• IFT2-RFM Radio Frequency Module
• AAA Alkaline Batteries (4)
• Wall Mount
• 1 inch #6 Screws (2)
• Drywall Anchors (2)
C. Installation Steps
CAUTION! Do not install damaged components. If
you received components that are damaged, contact your
dealer for assistance.
1. Remove the contents from the packaging.
2. Locate the IntelliFire Touch electronic control module
(IFT2-ECM) in the control cavity of the appliance and
move the three-position switch to the OFF position.
See Figure 1.
3. Connect the RFM to the ECM by aligning the pins and
tabs and pushing the RFM into the ECM until both
tabs snap into position. Ensure the two components
are fastened securely to one another. Be sure to
power down the ECM before inserting the RFM. See
Figure 1.
"OFF" POSITION
"OFF" POSITION
Figure 1 Connect IFT2-RFM to IFT2-ECM
Advertisement
Table of Contents
Related Manuals for Hearth & Home IntelliFire Touch IFT2-RC450
Summary of Contents for Hearth & Home IntelliFire Touch IFT2-RC450
- Page 1 IFT2-RC450 IntelliFire Touch 2.0 Remote Control ® Installation Instructions B. Kit Contents Leave this manual with party responsible for use • IFT2-RC450 Remote Control and operation. • IFT2-RFM Radio Frequency Module 1. Introduction • AAA Alkaline Batteries (4) The IntelliFire Touch Remote Control (IFT2-RC450) is a •...
- Page 2 4. Move the three-position switch on the IFT2-ECM to D. Pairing the IFT2-RC450 to the Electronic the REMOTE position. The green LED will blink three Control Module (IFT2-ECM) times. A few seconds later, an audible “beep” will oc- CAUTION! Risk of Burns! DO NOT program the IFT cur to indicate that the system is ready.
- Page 3 b. Re-Pairing existing IFT2-RC450 after add- 3. Locate reset button on back of the RC450 (opposite from “P” hole). Press and release the reset button with a paper ing IFT2-PACM, blower kit, light kit or clip (or similar object). power vent 4.
-
Page 4: Wall Mount Installation (Optional)
E. Brand/Dealer Programming Procedure F. Wall Mount Installation (Optional) This procedure allows the dealer to select the brand input 1. Detach the IFT2-RC450 from the wall mount. and dealer information for the consumer’s use. 2. Secure the wall mount on a flat wall surface using the The contact information will be accessible to the consumer two #6 screws and wall anchors provided. - Page 5 G. LCD Screen Calibration Procedure This procedure allows the dealer to calibrate the touch screen in the event that the screen becomes unresponsive to touch commands. 1. Insert the batteries and within one second press and hold the LCD screen. Continue pressing on the LCD screen for 6-8 seconds.
-
Page 6: Diagnostics Menu
H. Indicators Backup Battery Temperature Display The battery life indicator is for a backup power source for the IFT2-ECM located inside your appliance. It is You can toggle the temperature display between °F and intended to operate the appliance in the event of a power °C by tapping on the Room Temperature display. - Page 7 Indicators (continued) Replace Remote Batteries Sorry your appliance did not start. Must Replace Remote Batteries to Operate Try again by pressing Flame On. Appliance Your appliance did not start during the last Flame On Your remote batteries are low. Recommend immediate command.
-
Page 8: Troubleshooting
3. Troubleshooting NOTICE! Please contact your Heart & Home Technologies dealer if the Corrective Actions do not resolve the issues with your appliance. Symptom Possible Cause Corrective Action The appliance does not Batteries are depleted. Install NEW batteries. respond to commands from the IFT2-RC450 or display does Batteries are incorrectly Verify batteries are installed in correct orientation as... - Page 9 Troubleshooting (continued) Symptom Possible Cause Corrective Action The IFT2-RC450 displays the following message on- screen: Low batteries in the IFT2- “Replace Remote Batteries” Install new batteries in the IFT2-RC450. RC450. or “Must Replace Remote Batteries to Operate Appliance”. The IFT2-RC450 is Call dealer to have them program the IFT2-RC450 with The IFT2-RC450 was displaying an incorrect...
- Page 10 Troubleshooting (continued) Symptom Possible Cause Corrective Action IFT2-PACM was newly Make sure that the pairing procedure has been followed installed and not paired. especially if the IFT2-PACM was newly installed. The IFT2-PACM does not The power cord between Make sure the power cable is properly inserted into the respond to commands from IFT2-PACM and junction box IFT2-PACM and the junction box.
-
Page 11: Regulatory Certification
Regulatory Certification Canada The IFT2-RC450 is certified for use in Canada under The IFT2-RC450 wireless remote control is certified for Industry Canada (IC) Radio Standards Specification operation in the following countries: (RSS • United States • Canada This device complies with Industry Canada license exempt RSS standard(s).
