Specifications; Physical Dimensions - Delem DA-52s Installation Manual

2. Specifications

2.1. Physical dimensions

For the dimensions of the DA-52s control, see the included drawings at the end of this
section.
The following environment specification values are valid for a DA-52s control:
Ambient temperature
Storage temperature
Relative humidity
EMC
Enclosure
5 - 45°C
Warning:
Avoid long-term exposure of the control to direct
sunlight. Otherwise, the temperature inside the
control will rise above tolerance levels.
Operation of the control should be carried out
indoors.
min. -20°C
max. 70°C
max. 90 % non-condensing
designed and built to meet the following standards:
EN50081-2
EN60082-2
designed and built to meet the following standards:
IP20 (without optional enclosure)
IP54 (with optional enclosure)
Delem
V0614, 1.7
