DAC-300T series
The complete shear control
Operation Manual V1, EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DAC-300T Series and is the answer not in the manual?

Questions and answers

Related Manuals for Delem DAC-300T Series

Summary of Contents for Delem DAC-300T Series

  • Page 1 DAC-300T series The complete shear control Operation Manual V1, EN...
  • Page 2 This manual does not entitle you to any rights. Delem reserves the right to change this manual without prior warning. • All rights reserved. The copyright is held by Delem. No part of this publication may be copied or reproduced without written permission from Delem BV. V0819, 2...

  • Page 3: Table Of Contents

    Table of contents 1. Introduction ..........5 2. Using the DAC-300T ........6 2.1 User interface layout ..........6 2.2 Available menus............7 2.3 Key lock ..............8 2.4 On screen keyboard........... 9 3. Program selection mode ......11 3.1 Select a program from memory ....... 11 3.2 Copy/rename/delete a program from memory ..
  • Page 4 7. Diagnostics ..........42 7.1 Axis state..............42 7.2 Inputs and outputs ...........43 7.3 Signals ..............44 V0819, 4...

  • Page 5: Introduction

    Introduction The DAC-300T series is a programmable touch control for industrial cutting machines. Its user-friendly user interface is mainly based on icons, making it a fast and easy to program control. The high-quality widescreen TFT Color LCD display has a size of 7" and is equipped with an energy saving LED backlight.

  • Page 6: Using The Dac-300T

    User interface layout The user interface of the DAC-300T is based on the proven Delem touch interface introduced in the Delem press brake controllers. In the picture below the main layout of the screen is explained. This layout is applicable for all the operating modes for the DAC-300T, making the navigation easy and recognizable.

  • Page 7: Available Menus

    Information panel • Large working area • Context sensitive keyboard Command panel • Functions and soft keys belonging to the specific active function In order to select a menu item or parameter simply tap the screen once at the position of the icon. If it is necessary to pan (for example in product select menu), keep your finger on screen and move in the desired direction.

  • Page 8: Key Lock

    Settings Several control settings. The several modes are explained in detail in chapters 3 to 6. Key lock The control is equipped with a key lock function, to prevent unauthorised programming. It depends on the machine if this lock is accessible over the touch screen interface (upper left corner) or an external physical key switch.

  • Page 9: On Screen Keyboard

    • settings can be changed, • axes can be moved in manual movement mode, • in the manual mode it is still possible to program and execute one step. There is a second code available for the key lock function. When code 21 is entered instead of code 42 the user interface is blocked.
  • Page 10 Besides the numerical and alphanumerical keys there are some additional keys: Keyboard close Close the on screen keyboard. Caps lock Switch between lower- and upper-case characters. Special characters Switch the keyboard between normal and special characters. Enter key This function confirms the entered value, keeps the cursor on the selected input field and afterwards automatically closed the keyboard.

  • Page 11: Program Selection Mode

    Program selection mode By tapping the navigation button Program selection, the control is switched to program selection mode. Select a program from memory To select an existing program from the memory of the DAC- 300T, simply tap on the program to select it. When the program is successfully loaded the DAC-300T will display an information message on the screen that the program is loaded.
  • Page 12 Copy Create a copy of the selected program. When making a copy the DAC-300T will prompt the keyboard for the user to provide a new name. Rename Change the name of the selected program. When renaming the DAC-300T will prompt the keyboard for the user to provide a new name.

  • Page 13: Create A New Program

    Create a new program To create a new program, select the new program soft key. The DAC-300T will open the keyboard so the program name can be entered. If an already existing name is entered the DAC-300T will prompt a message and asks if the existing program should be over written or not.
  • Page 14 will invert to indicate that column position mode is active. While keeping the screen pressed move left or right to change the column position. V0819, 14...

  • Page 15: Automatic Mode

    Automatic mode By tapping the navigation button Automatic mode, the control is switched to Automatic mode. In Automatic mode a cutting program can defined or edited as explained in chapter 3. This chapter describes all possible parameters that can be programmed for a program step.

  • Page 16: Properties

    Properties The ‘Properties’ tab defines the general parameters that apply for all program steps. Material number The material of the sheet. There are 6 material types available. The material type will be used for angle, gap and force calculation. The corresponding values depend on the manufacturer settings.

  • Page 17: All Steps

    Sheet position Position of the sheet on the cutting table. Depending on the machine settings this parameter can also be found in the ‘All steps’ tab (programmable per cutting step). Stock counter To count the number of products. If programmed to 0, the counter will increase after each finished product.
  • Page 18 Start programming by entering values in the parameter fields. Some parameters are set automatically: angle, gap, stroke and force. All cutting step parameters can be changed if desired, including the pre-computed ones. If there are more parameters available than fits the screen, use the pan function to make the parameters visible.

  • Page 19: All Steps Parameters

    Delete step Select the number of the step that should be deleted. Press the ‘delete step’ soft key; the selected step will be deleted. The succeeding steps are shifted up. A complete program can be deleted in the program selection mode.
  • Page 20 X-axis position The desired backgauge position for this step. A positive value is an absolute position. A negative value is interpreted as a chaining value (a relative value). See also the parameter ‘Chaining mode’ in Settings mode, as described in paragraph 6.4. X2-axis position (DAC-362T only) The desired X2-position for this step.
  • Page 21 Sheet position Position of the sheet on the cutting table, programmable per step. Depending on the machine settings this parameter can also be found in the ‘Properties’ tab (programmable per program). Function output Binary value for the programmable digital outputs. The number of available outputs depends on machine settings.

  • Page 22: Program Execution

    Stroke length Stroke distance for this cut. Depending on machine settings, the stroke length is programmed as a distance or as a percentage of the maximum stroke. The stroke distance is automatically computed from sheet position, angle and cutting length; it can be changed if desired. Cutting force (DAC-36xT only) The desired force necessary for cutting the sheet.

  • Page 23: Manual Positioning

    To stop execution, press ‘Stop’. When the control is started in ‘All steps’ the screen will look like below: It highlights the active program step, actual X-axis position and the value of the stock counter. A program is repeated until 'Stop' is pressed or until the stock counter (#) has reached 0 after down counting.
  • Page 24 The distance moved with the slider determines the speed of the axis. When the slider is released, the axis stops. The buttons at each end of the slider can be used to fine-tune the axis position. When "sliding" the beeper gives feedback that the axis is moving.

  • Page 25: Manual Mode

    Manual mode By tapping the navigation button Manual, the control is switched to Manual mode. In this mode one cutting step can be programmed and executed. This chapter describes all possible parameters that can be programmed for a cutting step. Note that most of these parameters are machine configuration dependent;...
  • Page 26 pressed until its high-lighted and drag it to the desired position. Release the tile to fix the new position. Material number The material of the sheet. There are 6 material types available. The material type will be used for angle, gap and force calculation.
  • Page 27 X-axis park position With this parameter the backgauge can be set to its park position. This is for example applicable for de-coiling applications. When the parameter is set to disable the normal backgauge function is available. When set to enable the backgauge is moved automatically to its park position, and the X- axis parameters are made invisible.
  • Page 28 Part support (DAC-36xT only) Backside part support function on/off: • Disable -> Part support function inactive • Enable -> Part support function active Function output Binary value for the programmable digital outputs. The number of available outputs depends on machine settings. The name also depends on machine settings, and is FD by default.

  • Page 29: Program Execution

    Stroke length Stroke distance for this cut. Depending on machine settings, the stroke length is programmed as a distance or as a percentage of the maximum stroke. The stroke distance is automatically computed from sheet position, angle and cutting length; it can be changed if desired. Program execution When all the manual mode parameters have been programmed the single cut can be executed.

  • Page 30: Manual Positioning

    Manual positioning The manual positioning function of the axis in Manual mode is identical to the manual positioning in Automatic mode, see paragraph 4.5. V0819, 30...

  • Page 31: Settings Mode

    Settings mode By tapping the navigation button Settings, the control is switched to Settings mode. The Settings mode of the control gives access to all kind of settings which influence the programming of new products and programs. The settings are divided across several tabs logically organizing the different subjects.
  • Page 32 Language The user interface language can be selected from the list. There are more available languages than initially shown. Scroll vertically by dragging the list up and down to see all available languages. Tap to select the desired language for the user interface. Inch/mm-select Select to use either Millimeters or Inches as the unit to be used.

  • Page 33: Materials

    Materials Shear stress values for 6 different materials can be programmed. The values must be programmed in kN/mm2, regardless of the dimension and force setting in the ‘General’ tab. Note: This parameter is only present if cutting force control has been enabled.

  • Page 34: Backup / Restore

    Backup / restore When backup (restore) products, settings or all is selected for the first time a new window with a file browser is opened. In this window you can browse through the directory structure of your backup device. Tap the directory name on the right part of the file browser to look inside a subdirectory.
  • Page 35 Favourites -> add to favourites With ‘add to favourites’ it is possible to mark one or more specific directories as favourite. If there are favourite directories defined a button will be present in the upper right corner. By tapping this button, the defined favourites are presented, making a quick selection of the directory possible.

  • Page 36: Program Settings

    To backup (restore) a single product simply tap on the product to store it on the back-up device. To backup (restore) all products choose the ‘all’ soft key. Program settings V0819, 36...
  • Page 37 Thickness measurement (DAC-36xT only) Enable or disable sheet thickness measurement. When switched off, the information from the sensor will be ignored and only the programmed values for angle, gap, clamping force and cutting force will be used. When switched on, the parameters for angle, gap, clamping force and cutting force are not visible.

  • Page 38: Time Settings

    Opening above sheet With this parameter the opening above the sheet after a cut can be programmed. Time settings In the ‘Time settings’ tab, the date and time as displayed in the upper left corner of the screen can be changed. Display time Display date and time, time only or no time at all on the title panel.

  • Page 39: Maintenance

    Date format Display the date in dd-mm-yyyy, mm-dd-yyyy or yyyy- mm-dd format. Adjust time To adjust the date and time. Adjusting the date and time will also adjust the date and time of the operating system. Maintenance On this tab maintenance related functions are located. Next to the machine hour counter and the machine stroke counter also functions to calibrate the backgauge and to store diagnostic data can be found here.

  • Page 40: System Information

    Lock screen To lock the screen, and e.g. clean the screen without changing anything. The screen is unlocked automatically after 5 seconds. Create .dat-file Tapping Create .dat-file will store the most important product and control data, by default on the connected USB stick. This information can be helpful for the maintenance support.
  • Page 41 The backup system function makes a complete system backup to a USB stick. A unique time stamped file is written on the USB stick. This backup holds Delem software, OEM specific data as well as the user's files. Restore system The restore system function can be used to restore an earlier made backup of the system.

  • Page 42: Diagnostics

    Diagnostics If the service row is pressed for 2 seconds in Automatic mode or Manual mode the DAC-300T will enter its built-in diagnostic mode. The diagnostic mode can be switched off by tapping the service row again. These diagnostic screens are intended to be used on request of a service engineer from the machine manufacturer.

  • Page 43: Inputs And Outputs

    • S2 -> Wait for ST low • S3 -> Wait for EOS • S4 -> Wait for UDP • S5 -> Wait for STEP high • S6 -> Wait for Retract • S7 -> Wait for safe X Inputs and outputs The status of all inputs, outputs and encoders is displayed.

  • Page 44: Signals

    Signals The status of all digital input and output signals is displayed. V0819, 44...
  • Page 45 INTENTIONALLY LEFT BLANK V0819, 45...
  • Page 46 INTENTIONALLY LEFT BLANK V0819, 46...
  • Page 47 INTENTIONALLY LEFT BLANK V0819, 47...
  • Page 48 The DAC-300T is a complete, versatile unit for control of industrial shears. 8095-931A...
