Connector - Component Diagram Frame 19 (A.30.A.87 - C.20.F.19) - Case 435 Repair Manual

Connector - Component diagram frame 19 (A.30.A.87 - C.20.F.19)

435, 445, 445CT
Cavity
85
85
86
30
86
87
Cavity
A
B
C
D
Cavity
A
B
DISTRIBUTION SYSTEMS - ELECTRICAL POWER SYSTEM
178DF (B)
178DG (B)
320B (LB)
622D (W)
320A (LB)
624A (DB)
602D (W)
622D (W)
319E (T)
178DF (B)
604A (W)
624A (DB)
Connector 125
1
245731C1
Circuit ID
Connector 127B
2
256347A1
Circuit ID
Connector 127C
3
256346a1
Circuit ID
1 04/05/2005
A.30.A / 42
Description
From connector 127B pin D
From connector 128 pin 85
To connector 129 pin A
To connector 127B pin B
To connector 130 pin B
To connector 127C pin B
Description
From connector 128 pin 30
From connector 125 pin 30
From connector 129 pin B
From connector 125 pin 85
Description
From connector 128 pin 87
From connector 125 pin 87
