Connector - Component Diagram Frame 11 (A.30.A.87 - C.20.F.11) - Case 435 Repair Manual

Connector - Component diagram frame 11 (A.30.A.87 - C.20.F.11)

435, 445, 445CT
Cavity
A
B
C
Cavity
A
B
Cavity
1
2
DISTRIBUTION SYSTEMS - ELECTRICAL POWER SYSTEM
535A (T)
751B (R)
178BE (B)
535C (T)
178BT (B)
178BR (B)
545B (T)
Connector 72
1
245432C1
Circuit ID
Connector 120
2
245482c1
Circuit ID
Connector 121
3
291718a1
Circuit ID
1 04/05/2005
A.30.A / 30
Description
From connector 124 pin B
From primary fuse block
To ground
Description
From connector 124 pin B
To connector 124 pin A
Description
From splice 2
To connector 123 pin A
