SKID STEER/COMPACT TRACK LOADER
87634765 NA
Issued 01Jan08
REPAIR MANUAL
SERIES 3
410
420
420CT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 410 and is the answer not in the manual?

Questions and answers

Related Manuals for Case 410

Summary of Contents for Case 410

  • Page 1 REPAIR MANUAL SKID STEER/COMPACT TRACK LOADER 420CT SERIES 3 87634765 NA Issued 01Jan08...
  • Page 2 REPAIR MANUAL REPAIR MANUAL SKID STEER/ SKID STEER/ COMPACT TRACK LOADERS COMPACT TRACK LOADERS 420CT 420CT SERIES 3 SERIES 3 87634765 NA 87634765 NA 1. Trim along dashed line. 1. Trim along dashed line. 2. Slide into pocket on Binder Spine 2.
  • Page 3 Tab 2 Section Index - Engines 6-79051 Engine and Radiator Removal and Installation 2000 6-79130 Engine and Radiator Removal and Installation (410 Tier 3 Engines) 2000 5-7650 Engine and Radiator Removal and Installation (420/420CT Tier 3 Engines) 2000 5-7660 For Engine Repair - See Engine Repair Manual...
  • Page 4 410/420 SKID STEER AND 420CT COMPACT TRACK LOADER Repair Manual Mechanical and Pilot Control Machines (Tier 3 and Cab Up-Grade Machines) Bur 87634765 Table of Contents (Continued) Publication Description Section Number Form Number Power Train Tab 6 Section Index - Power Train 6-79081 Hydrostatic System”How it Works”...
  • Page 5 410/420 SKID STEER AND 420CT COMPACT TRACK LOADER Repair Manual Mechanical and Pilot Control Machines (Tier 3 and Cab Up-Grade Machines) Bur 87634765 Table of Contents (Continued) Publication Description Section Number Form Number Mounted Equipment Tab 9 Section Index - Mounted Equipment...
  • Page 6 410/420 SKID STEER AND 420CT COMPACT TRACK LOADER Repair Manual Mechanical and Pilot Control Machines (Tier 3 and Cab Up-Grade Machines) Bur 87634765 Table of Contents (Continued) NOTES Bur 6-78992 Revised 12-07 Printed in U.S.A. Find manuals at https://best-manuals.com...
  • Page 7 SECTION INDEX GENERAL Section Title Section Number Fluids and Lubricants ..............1001 Fluids and Lubricants - Tier 3 Engines .
  • Page 8 Find manuals at https://best-manuals.com...
  • Page 9 Section 1001 FLUIDS AND LUBRICANTS Copyright © 2006 CNH America LLC CNH AMERICA LLC Printed in U.S.A. 700 State Street Racine, WI 53404 U.S.A. Bur 6-79031 Issued February, 2005 (Revised March, 2006) Find manuals at https://best-manuals.com...

  • Page 10: Table Of Contents

    1001-2 TABLE OF CONTENTS CAPACITIES AND LUBRICANTS ............. 3 ENVIRONMENT .

  • Page 11: Capacities And Lubricants

    Capacity - with filter change ....................8.7 litres (9.2 quarts) Capacity - without filter change ....................8.5 litres (9 quarts) Specifications ............. Case Akcela No. 1 Engine Oil SAE 10W-30 (API service CH-4) ..................(See Oil Viscosity/Temperature Ranges Chart on page 4) ENGINE CRANKCASE OIL (430/440 and 440CT MACHINES) Capacity - with filter change ....................

  • Page 12: Engine Lubrication

    Case Akcela No. 1 Engine Oil is recommended for NOTE: Do not put Performance Additives or other oil use in your Case Engine. Case Akcela Engine Oil will additive products in the engine crankcase. The oil lubricate your engine correctly under all operating change intervals given in the operating manual are conditions.

  • Page 13: Diesel Fuel System

    1001-5 DIESEL FUEL SYSTEM Fuel Storage Use No. 2 diesel fuel in the engine of this machine. The use of other fuels can cause the loss of engine If you keep fuel in storage for a period of time, you power and high fuel consumption.
  • Page 14 1001-6 NOTES Bur 6-79031 Revised 3-06 Printed in U.S.A.
  • Page 15 Section 1001 FLUIDS AND LUBRICANTS Copyright © 2007 CNH America LLC CNH AMERICA LLC Printed in U.S.A. 700 State Street Racine, WI 53404 U.S.A. Bur 5-7580 Issued December, 2007...
  • Page 16 1001-2 TABLE OF CONTENTS CAPACITIES AND LUBRICANTS ............. 3 ENVIRONMENT .

  • Page 17: Capacities And Lubricants

    Capacity - with filter change.................. 10.5 litres (11.1 U.S.quarts)) Capacity - without filter change................9.9 litres (10.5 U.S.quarts)) Specifications..........Case Akcela No. 1 Engine Oil SAE 10W-30 (API service CH-4) ................(See Oil Viscosity/Temperature Ranges Chart on page 5) Bur 5-7580 Issued 12-07 Printed in U.S.A.

  • Page 18: Environment

    Capacity - with filter change..................8.5 litres (9 U.S.quarts)) Capacity - without filter change..................8.0 litres (8 U.S.quarts)) Specifications..........Case Akcela No. 1 Engine Oil SAE 15W-40 (API service CH-4) ................(See Oil Viscosity/Temperature Ranges Chart on page 5) ENVIRONMENT Before you service this machine and dispose of oil, fluids and lubricants, always remember the environment.

  • Page 19: Engine Lubrication

    Case Akcela No. 1 Engine Oil is recommended for NOTE: Do not put Performance Additives or other oil use in your Case Engine. Case Akcela Engine Oil will additive products in the engine crankcase. The oil lubricate your engine correctly under all operating change intervals given in the operating manual are conditions.

  • Page 20: Diesel Fuel System

    1001-6 DIESEL FUEL SYSTEM Fuel Storage Use No. 2 diesel fuel in the engine of this machine. The use of other fuels can cause the loss of engine If you keep fuel in storage for a period of time, you power and high fuel consumption.
  • Page 33 Engine and Radiator Removal and Installation (410 Tier 3 Engines) .......
  • Page 35 Section 2000 410 ENGINE AND RADIATOR REMOVAL AND INSTALLATION Tier 3 Engines Copyright © 2007 CNH America LLC CNH AMERICA LLC Printed in U.S.A. 700 State Street Racine, WI 53404 U.S.A. Bur 5-7650 December, 2007...
  • Page 36 2000-2 TABLE OF CONTENTS RADIATOR ................3 Removal .
  • Page 37 2000-3 RADIATOR Removal STEP 6 NOTE: Put caps on all fittings and plugs in all disconnected hoses. STEP 1 Park the machine on a level surface. STEP 2 Lift the hood and open the rear access door on the machine. STEP 3 BD07M176-01 Turn the ignition switch and the master disconnect...
  • Page 38 2000-4 STEP 9 STEP 12 BD07K011-01 BD07K006-01 Loosen the clamp (1) on the upper radiator hose and Remove the cap (1) from the hydraulic reservoir. remove the hose from the upper radiator connection. Connect a vacuum pump to the hydraulic reservoir. Start the vacuum pump.
  • Page 39 4. LOWER RADIATOR HOSE 12. FAN GUARD 5. COOLANT RECOVERY HOSE 13. FAN SHROUD 6. COOLANT RECOVERY BOTTLE 14. SEAL 7. CLAMP 15. RADIATOR CAP 8. LOWER HINGE MOUNTING BRACKET 16. DRAIN VALVE 410 RADIATOR MOUNTING Bur 5-7650 Issued 12-07 Printed in U.S.A.
  • Page 40 2000-6 Installation STEP 15 Installation of the radiator is the reverse procedure of removal. STEP 16 After the radiator has been installed, fill the cooling system. See Section 1001 for the correct coolant mixture and quantity. STEP 17 Start and run the engine until it reaches operating temperature and check for any leaks.
  • Page 41 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
