56
When the data is being recorded, there is a flashing red symbol in
the top left corner and a message appears periodically at the
bottom of the screen.
Filename
Specify the name of the recording (log).
File format
Select a file format from the drop-down, slg (Sonar only), xtf
(Structure only*), or sl2 (Sonar and Structure).
Ú Note:
XTF format is for use only with select 3rd party Sonar
viewing tools.
Save to
Select whether the recording is to be saved internally or to a
memory card in the card reader.
Create StructureMap
Ú Note:
This option is only available on models that have
TripleShot/StructureScan capability.
If your model has TripleShot/StructureScan capability, you can
convert the .sl2 logs to StructureMap format (.smf) when recording
completes.
The log file can also be converted to StructureMap format from the
Files option.
Time remaining
Shows the remaining allocated space available for recordings.

Stop recording sonar log data

Select Stop logging in the System Controls dialog and then Stop in
the Logging Sonar dialog to stop the recording of all sonar log data.
Sonar | Hook² Series Operator Manual
