  • Page 1 Smile Room Connect System Installation Instructions MU1H-0635GE51 R1016...
  • Page 2: Table Of Contents

    Smile Room Connect SRC-10 Installation Instructions Table of Contents Safety instructions ............... 4 Intended use ................. 4 Electric installation ..............4 System Description ..............5 Local operation for HR92 and T87RFxx ......... 7 Scope of supply ..............8 Accessories ................9 Installation and electrical connection ........
  • Page 3 Installation Instructions Smile Room Connect SRC-10 4.2.4 Set up heating mode ............. 32 4.2.4.1 Set lowering mode ..........32 4.2.4.2 Regulation gain ............33 4.2.4.3 Regulation adjust time ..........34 4.2.4.4 Regulation scan time ..........35 4.2.4.5 Reset ..............36 SRC-10 start-up ..............
  • Page 4: Safety Instructions

    1 Safety instructions 1.1 Intended use • The SRC-10 (Smile Room Connect) can be operated via a smart phone and an app. You can therefore control the temperatures in individual rooms through several wireless devices. • The devices are not intended for children and should not be used as toys.
  • Page 5: System Description

    Smile Room Connect SRC-10 Installation Instructions 2 System Description Fig. 1: SRC-10 system overview MU1H-0635GE51 R1016...
  • Page 6 The SRC-10 is an upgradable module for the Smile Connect System. Individual room control in accordance with EN 15232 is possible through a boiler connection. To ensure individual room control, there are different components that allow the temperature in each room to be selected. Remote access via an app is also possible.
  • Page 7: Local Operation For Hr92 And T87rfxx

    Smile Room Connect SRC-10 Installation Instructions The basic settings (min-max values, frost protection value, etc.) for individual rooms are given in the SCN-10, Pro menu under room groups. From these settings, the system calculates a flow set point which is transmitted to the controller. For more information on the basic settings, see chapter 4.2 Rooms basic settings.
  • Page 8: Scope Of Supply

    The Smile App is installed on mobile devices such as smart phones or tablets (iOS or Android) and is used to operate the SRC-10. You can download the app using the search term "Honeywell Smile" from the App Store and from the Google Play Store free of charge.
  • Page 9: Accessories

    Smile Room Connect SRC-10 Installation Instructions • Network cable (x 1), • Wall power supply for Smile Room Connect (x 1), • Operating instructions (x 1). 2.3 Accessories The following component is available as an accessory and is essential for start-up: •...
  • Page 10: Installation And Electrical Connection

    3 Installation and electrical connection Follow the specified sequence during installation and start-up of the SRC-10. Install the SCN-10 completely. Install the SRC-10. 3.1 Prerequisites and requirements The SCN-10 requires an Ethernet network (LAN/WLAN) including router. In order to use the SRC-10, you will need a smart phone or tablet (iOS versions which are under support of Apple, or Android 4.x or higher from 8"...
  • Page 11: Installation

    Smile Room Connect SRC-10 Installation Instructions 3.1.1 Installation The SRC-10 is provided as a table-top device. Find a suitable installation location that fulfills the following requirements: • A 230-V earthed wall socket must be available. • The installation location must be within the radio coverage area.
  • Page 12 Fig. 2: SRC-10 radio coverage MU1H-0635GE51 R1016...
  • Page 13: Electrical Connection

    Installation Instructions 3.1.2 Electrical connection Fig. 3: Smile Room Connect SRC-10 1. Connect the SRC-10 to the customer's LAN network: Via a network cable into an available Ethernet port on the customer's internet router or switch. The length of the total cable from the SRC-10 to the next switch or router must not exceed 100 m.
  • Page 14: Start-up/initial Setup

    4 Start-up/Initial setup NOTE Before you can configure the SRC-10, you must set up the rooms that are to be operated in advance in the SCN-10 and activate the individual room regulator, see chapter 4.1, SCN-10 configuration. Start-up includes configuring the SCN-10 via a browser (e.g., Internet Explorer, Chrome, Firefox) on the connected PC/laptop.
  • Page 15: Scn-10 Configuration

    Smile Room Connect SRC-10 Installation Instructions 4.1 SCN-10 configuration The SCN-10 is configured on a PC/laptop using the setup wizard (see detailed description in the Smile Connect System installation instructions, MU1H-0603GE51, chapter 4.1). Plug the USB-LAN adapter into an available USB port on the upper side of the Smile Connect.
  • Page 16 1. Click on Setup Wizard. MU1H-0635GE51 R1016...
  • Page 17 Smile Room Connect SRC-10 Installation Instructions 2. The Network menu will appear. 3. To access the next menu, press the button. 4. The Energy Generator screen will appear. MU1H-0635GE51 R1016...
  • Page 18 5. Click on Single room heat regulation and select On in the drop-down menu. 6. Activate individual room regulation by pressing OK. MU1H-0635GE51 R1016...
  • Page 19 Smile Room Connect SRC-10 Installation Instructions 7. The Rooms screen will appear. 8. Using the button, you can set up the rooms that are to be operated. More information on setting up rooms can be found in the Smile Connect System installation manual, MU1H-0595GE51, chapter 4.1, sections 20-21.
  • Page 20: Rooms Basic Settings

    4.2 Rooms basic settings The following chapter shows the menu for the basic settings for individual rooms on the SCN-10. The settings for each room can be selected individually. Room 1 is shown as an example. MU1H-0635GE51 R1016...
  • Page 21: General Room Information

    Smile Room Connect SRC-10 Installation Instructions 4.2.1 General room information Under Information, you can see general room information. MU1H-0635GE51 R1016...
  • Page 22: General Basic Settings

    4.2.2 General basic settings Under Basic Settings, you can set requests, room deactivation, frost protection mode, and a default name. 4.2.2.1 Define requests Here you can set the room regulation. MU1H-0635GE51 R1016...
  • Page 23: Set Room Blocking

    Smile Room Connect SRC-10 Installation Instructions 4.2.2.2 Set room blocking Here you can choose between Room blocking Off and 0.1K-5.0K. If the current room temperature exceeds the room set value, then the request to the heat generator will turn off.
  • Page 24: Activate Frost Protection Mode

    4.2.2.3 Activate frost protection mode Here you can choose between Frost Protection Temperature or Night. MU1H-0635GE51 R1016...
  • Page 25: Change Room Names

    Smile Room Connect SRC-10 Installation Instructions 4.2.2.4 Change room names Here you can change the name of the room. MU1H-0635GE51 R1016...
  • Page 26: Adjusting Room Settings

    4.2.3 Adjusting room settings Specific settings can be made to the rooms under Room settings. 4.2.3.1 Set room maximum temperature Here you can set the maximum room temperature. MU1H-0635GE51 R1016...
  • Page 27: Comfort Hi - Set High Comfort Temperature

    Smile Room Connect SRC-10 Installation Instructions 4.2.3.2 Comfort hi – set high comfort temperature Here you can set the increased comfort temperature. MU1H-0635GE51 R1016...
  • Page 28: Comfort Low - Set Low Comfort Temperature

    4.2.3.3 Comfort low – set low comfort temperature Here you can set the reduced comfort temperature. MU1H-0635GE51 R1016...
  • Page 29: Set Night Temperature

    Smile Room Connect SRC-10 Installation Instructions 4.2.3.4 Set night temperature Here you can set the night temperature. MU1H-0635GE51 R1016...
  • Page 30: Offset Fast Heating Setting

    4.2.3.5 Offset fast heating setting Here you can select fast heating. You can choose between 0.5 K and 4.0 K. MU1H-0635GE51 R1016...
  • Page 31: Offset Economy Setting

    Smile Room Connect SRC-10 Installation Instructions 4.2.3.6 Offset economy setting Here you can set a offset economy value. You can choose between 0.5 K and 4.0 K. MU1H-0635GE51 R1016...
  • Page 32: Set Up Heating Mode

    4.2.4 Set up heating mode Under Heating mode, you can set the offset heating operation settings. 4.2.4.1 Set lowering mode Here you can choose between ECO mode and Lowering mode (ABS). MU1H-0635GE51 R1016...
  • Page 33: Regulation Gain

    Smile Room Connect SRC-10 Installation Instructions 4.2.4.2 Regulation gain You can choose between 1.0%/K and 100%/K. MU1H-0635GE51 R1016...
  • Page 34: Regulation Adjust Time

    4.2.4.3 Regulation adjust time Here you can choose between 5.0 min and 240.0 min. MU1H-0635GE51 R1016...
  • Page 35: Regulation Scan Time

    Smile Room Connect SRC-10 Installation Instructions 4.2.4.4 Regulation scan time Here you can choose between 1.0 min and 300.0 min. MU1H-0635GE51 R1016...
  • Page 36: Reset

    4.2.4.5 Reset Here you can choose between Off and Reset. MU1H-0635GE51 R1016...
  • Page 37: Src-10 Start-up

    Smile Room Connect SRC-10 Installation Instructions 4.3 SRC-10 start-up After configuring the SCN-10, you can begin starting up the SRC-10. Fig. 4: Initial setup SRC-10 The initial setup of the SRC-10 is performed via the setup wizard menu on the browser of the connected PC/laptop.
  • Page 38 1. Connect the SCI-10 USB-LAN adapter from the installation kit to the SRC-10 and the PC/laptop: 2. Plug the SCI-10 USB-LAN adapter into an available USB port on the upper side of the SRC-10. 3. Turn on the PC/laptop. Connect the SCI-10 USB-LAN adapter to the network port of the PC/laptop.
  • Page 39: Setup Wizard

    Smile Room Connect SRC-10 Installation Instructions 5 Setup wizard The setup wizard of the SRC-10 takes you through the basic settings. Log in 1. Log in with the access data for the SRC-10. NOTE You do not need to log in into the system during the initial setup.
  • Page 40 3. Click on Setup Wizard. 4. The Network screen will appear. MU1H-0635GE51 R1016...
  • Page 41 Smile Room Connect SRC-10 Installation Instructions Network A functioning network in your house or apartment is required for installation. An internet connection is not required for this. If you don't have an internet connection, you can only operate the system with your smart phone or tablet from your home and not while on the move.
  • Page 42 Establishing a network connection • LAN connection via DHCP, recommended (automatic installation of the internet connection), • LAN connection with manual settings (optional), • Setting up a WLAN connection (optional), • Setting up a proxy connection (optional). 5. You can access the Connection Smile Gateway SCN-10 menu by pressing the button.
  • Page 43 Smile Room Connect SRC-10 Installation Instructions Password Enter a password to access the SRC-10. NOTE If you have already changed the password of your Smile Room Connect, then you can skip this section. If you'd like to change your password again, then please click on Change password.
  • Page 44: Setting Up The Radio Components

    6 Setting up the radio components The SRC-10 must be set up completely according to chapter 4.3 SRC-10 start-up. The LED on the side should have a GREEN light. 1. Log in with your chosen password. 2. Register all radio components on the SRC-10 according to the following descriptions.
  • Page 45: General Description Of The Binding Process

    Smile Room Connect SRC-10 Installation Instructions 6.1 General description of the binding process 1. Select Radio components. MU1H-0635GE51 R1016...
  • Page 46 2. The Radio components screen will appear. NOTE The rooms that were set up in SCN-10 are automatically transferred to the SRC-10 and will be displayed. 3. You can add a new radio component by pressing button. MU1H-0635GE51 R1016...
  • Page 47 Smile Room Connect SRC-10 Installation Instructions 4. The Add radio component screen will appear. 5. Select the radio components that you’d like to add. 6. The Add radio component screen will appear. MU1H-0635GE51 R1016...
  • Page 48 7. Follow the instructions on the screen of the respective radio component. 8. Click on Proceed to start the binding process between the radio component and the SRC-10. MU1H-0635GE51 R1016...
  • Page 49: Display Description

    Smile Room Connect SRC-10 Installation Instructions 6.1.1 Display description Once the binding process is complete, the components in the selected room will be displayed. This process may take a few seconds. Room name Battery status Current room temperature Setting the desired room temperature...
  • Page 50: Binding Heat Generator Regulator Hr92

    6.2 Binding radiator controller HR92 1. Insert batteries. 2. Press the button once: NO BIND should appear on the display screen. 3. Press the button for 5 seconds until BIND appears on the display screen. 4. Press the button once: BINDING should appear on the display screen.
  • Page 51: Binding T87rfxx

    Smile Room Connect SRC-10 Installation Instructions 6.4 Binding T87RFxx 1. Press and hold the right sensor button for approx. 10 seconds and then start the binding process. 2. The notification "bnd" will appear on the screen. 3. Briefly press the right sensor button again to send the binding signal.
  • Page 52: Binding Underfloor Heating Controller Hce80 Or Hcc80

    6.5 Binding underfloor heating controller HCE80 or HCC80 NOTE A underfloor heating controller can be assigned to a room only if a set value adjuster or a room sensor has been previously assigned to the room. 1. Press and hold the Bind button on the underfloor heating controller until the LED of the corresponding room (zone) flashes.
  • Page 53: Perform System Test

    Smile Room Connect SRC-10 Installation Instructions 6.6 Perform system test When all the devices are connected to the SRC-10 and are installed, perform a brief system test. You can perform a simple function test of the heating system by setting the room set value temperature of each room to the corresponding minimum and maximum temperatures.
  • Page 54 5. The signal strength of the last received message is shown by the following color levels: Radio reception very good Radio reception adequate No radio reception 6. If the SRC-10 is defective, all radio components must be reconnected after the device has been replaced. MU1H-0635GE51 R1016...
  • Page 55: Perform System Update

    Smile Room Connect SRC-10 Installation Instructions 8 Perform system update Setting up System Updates can be carried out under the System Administration menu. As soon as a system update is required, the following message will appear: 1. To start the system update, click on System Update.
  • Page 56 2. The Room Connect SRC-10 system update screen will appear. 3. Click on execute update. 4. The update will start. MU1H-0635GE51 R1016...
  • Page 57 Smile Room Connect SRC-10 Installation Instructions 5. Confirm the update by clicking OK. You can now continue with the operation. MU1H-0635GE51 R1016...
  • Page 58: Technical Data

    9 Technical data Table-top device Installation Linux Operating system • Connections USB 2.0 • RJ45 Ethernet • Mini USB for power supply • Integrated WiFi module Euro wall plug transformer 5 V DC, 1 A Power supply Environmental conditions • Storage temperature -25 to +60°C •...
  • Page 59 Smile Room Connect SRC-10 Installation Instructions MU1H-0635GE51 R1016...
  • Page 60 Manufactured for and on behalf of the Environmental and Energy Solutions Division of Honeywell Technologies Sàrl, Rolle, Z.A. La Pièce 16, Switzerland by its Authorized Representative: Automation and Control Solutions Honeywell GmbH Böblinger Straβe 17 71101 Schönaich, Germany Phone +49 (0) 7031 637 01 +49 (0) 7031 637 740 http://ecc.emea.honeywell.com...
