Before commencing assembly please read these instructions thoroughly
Wing Span: 36.4 in / 925 mm
Wing Area: 346 sq in / 22.3 sq dm
Flying Weight: 28.3 oz / 800 g
Fuselage Length: 41.5 in / 1055 mm
Requires: 4-channel radio w/ 4 micro servos, 2 x Outrunner Motor
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
* Specifications are subject to change without notice.*
THE WINGS MAKER
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
.
www thewingsmaker com
GM070XMPO30681411
,
Specifications
Specifications
KM28251025 w/ Propeller Adaptor HW234040R &
HW2340400, 2 x 15A Brushless ESC,8x4E & 8x4P Propeller,
3 cells 11.1V 1800 mAh Li-Po battery & charger.
.
I NSTRUCTI ON M ANUAL
( GM070XM )
.
Advertisement
Table of Contents
Related Manuals for The Wings Maker Handyman Twins
Summary of Contents for The Wings Maker Handyman Twins
- Page 1 Operating this model without prior preparation may cause injuries. Remember, safety is the most important thing. Always keep this instruction manual at hand for quick reference. * Specifications are subject to change without notice.* THE WINGS MAKER FACTORY PRE-FABRICATED ALMOST-READY-TO-FLY (ARF) SERIES MADE IN CHINA...
-
Page 2: Before You Begin
INDEX BEFORE YOU BEGIN PARTS LIST ASSEMBLY P.3-P.11 SAFETY PRECAUTIONS P.12 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. Check all parts. If you find any defective or missing parts contact your local dealer. Please DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly. -
Page 3: Parts List
Parts List 1.DECALS: GM070XM DEC -- 1 set 10.MAIN LANDING GEAR Ø2.5mm -- 1 set MAIN WING -- 1 pair COLLAR Ø2.6mm w/ Set Screw -- 2 sets STABILIZER & ELEVATOR -- 1 set MAIN WHEEL Ø40mm PL3116040 -- 2 pcs VERTICAL FIN &... - Page 4 Decals Cut out decal sheet, peel off backing sheet and apply on fuselage, stabilizer and wings. Decal Main wings Top View Bottom View Stabilizer Rudder Top View Left View Right View Bottom View After applying the thunderbolt decals across the hinge line, cut it to allow free movement of the Stabilizer.
-
Page 5: Stabilizer & Elevator
Stabilizer & Elevator Hinge Setting Hinge Section View Completed Hinge For pre-assembled version, the hinges are factory glued. Bottom View Vertical Fin & Rudder Hinge Setting Hinge Section View Completed Hinge Right View For pre-assembled version, the hinges are factory glued. Decals for Rudder After applying the thunderbolt decals across the hinge line, cut it to allow free movement of the Rudder. -
Page 6: Rudder Pushrod
Rudder Servo & Horn Servo wire Plastic Bracket Horn For pre-assembled version, the horn is factory glued and servo installed. Rudder Pushrod Straper Servo Mount Fuel Tube d2xD4x4mm Pushrod Ø1.4x125mm Clevis Fuel Tube d2xD4x4mm Horn Elevator Servo & Horn Servo wire Plastic Bracket Horn Bottom View... -
Page 7: Elevator Pushrod
Elevator Pushrod Plastic Stand Fuel Tube Straper d2xD4x4mm Fuel Tube d2xD4x4mm Pushrod Ø1.4x50mm Clevis Horn Bottom View Tail Landing Gear PA2x10mm Screw Wheel Ø23mm Plastic PA2x10mm Collar 1.2mm Bottom View Bottom View Main Landing Gear PM2x14mm Screw d2xD5mm Washer Plywood Nylon Insert Lock Nut 26x40x2.5mm d2xD5mm Washer... -
Page 8: Nose Piece
Nose Piece Aileron Servo & Horn Hinge Setting Hinge Section View Completed Servo Mount Hinge Bottom View Servo Mount Horn Bottom View For pre-assembled version, the hinges and horn are pre-glued, and servo installed. GM070XMPO30681411... -
Page 9: Motor Installation
Aileron Pushrod Fuel Tube d2xD4x4mm Straper Plastic Stand Fuel Tube d2xD4x4mm Pushrod Ø1.4x76mm Clevis Horn Bottom View Motor Installation 8x4E Propeller PL6210804 M3x8mm Socket Head Screw M5 Nut (Reverse) Propeller Adaptor HW234040R d3xD7mm Washer Plywood 30x60x4mm(L) 8x4P Propeller PL6210804P M3x8mm M5 Nut d3xD7mm Propeller Adaptor HW2340400... - Page 10 Main Wing PM3x20mm Screw PM3x20mm Wing Tube Ø6x365mm Insert carbon fiber wing tube into right wing, align the anchor holes and apply the PM Screw. PM3x20mm Insert the right wing into the Fuselage. Inset the left wing onto the carbon wing tube, press the wings against the fuselage align the anchor holes and apply the PM Screw.
- Page 11 Radio Plug in with red+ / black- reversed will damage the ESC. Motor Brushless ESC Battery Receiver EZ Connector Puller EZ Power Y-Cord For Twin ESC 180mm Y-Cord KW1210060 Motor Brushless ESC Connect the three motor wires of the left motor to the left ESC, and right motor to the right ESC. Connect the throttle control wires of the two ESCs to the Y-chord.
-
Page 12: Battery Cover
Battery Cover Control Throws Adjust the control throws as shown in the diagram. These throws are good for Elevator general flying. You can adjust according 50mm to your personal preference. 50mm Rudder 60mm 60mm Ailerons 40mm 40mm C.G. The ideal C.G. position is 120mm (4.7 in.) behind the leading edge measured at where the wing meets the fuselage. -
Page 13: Important Safety Precautions
Warning! Important Safety Precautions # First time flyer should never fly by himself / herself. Assistance from experienced flyer is absolutely necessary. # Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft. is specially designed to be powered by KM28251025 Outrunner Motor. - Page 14 Pl8210010 Large Clevis Small Clevis 180mm Y-Cord Code No. Size Package KW0021800 180mm 1 pc Outrunner Motor KM28251025 EZ Power Y-Cord For Twin ESC Code No. Size Package KW1210060 1 pc -Kv (rpm/V): 1025 -Operating Power: 110W -Operating Voltage: 2-3S Li-Po -Operating Current: 10A EZ Connector Puller -Peak Current: 15A (max.
- Page 15 8x4E Propeller 8x4P Propeller Code No. Size Package Code No. Size Package PL6210804 1 pc PL6210804P 1 pc GM070XMPO30681411...
- Page 16 THE WINGS MAKER GM070XMPO30681411...
