OBJ_BUCH-1077-009.book Page 15 Wednesday, November 2, 2016 4:41 PM
Noise/Vibration Information
Grass Shear
Sound emission values determined according to
EN 50636-2-94.
Typically the A-weighted sound pressure level of the product
is less than 70 dB(A).
Vibration total values a
(triax vector sum) and uncertainty K
h
determined according to EN 50636-2-94:
2
2
a
=2,5 m/s
, K =1,5 m/s
.
h
Vibration-emission-level
1)
Shrub Shear
Sound emission values determined according to
EN 60745-2-15.
Typically the A-weighted noise levels of the product are:
Sound pressure level 66 dB(A); sound power level 76 dB(A).
Uncertainty K =1 dB.
Vibration total values a
(triax vector sum) and uncertainty K
h
determined according to EN 60745-2-15:
2
2
a
=2.5 m/s
, K =1.5 m/s
.
h
Vibration-emission-level
1)
1) The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with another.
It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This may
significantly increase the exposure level over the total working
period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or when
it is running but not actually doing the job. This may significantly
reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from
the effects of vibration such as: maintain the tool and the acces-
sories, keep the hands warm, organisation of work patterns.
Declaration of Conformity
Grass Shear
We declare under our sole responsibility that the product de-
scribed under "Technical data" is in conformity with all rele-
vant provisions of the directives 2014/35/EU,2011/65/EU,
until 19 April 2016: 2004/108/EC, from 20 April 2016 on:
2014/30/EU, 2006/42/EC including their amendments and
complies with the following standards: EN 60335-1,
EN 50636-2-94 (battery powered product), EN 50581,
EN 60335-1, EN 60335-2-29 (battery charger).
Bosch Power Tools
Shrub Shear
We declare under our sole responsibility that the product de-
scribed under "Technical data" is in conformity with all rele-
vant provisions of the directives 2014/35/EU, 2011/65/EU,
until 19 April 2016: 2004/108/EC, from 20 April 2016 on:
2014/30/EU, 2006/42/EC, 2000/14/EC including their
amendments and complies with the following standards:
EN 60745-1, EN 60745-2-15 (battery powered product),
EN 50581, EN 60335-1, EN 60335-2-29 (battery charger).
2000/14/EC: Guaranteed sound power level 77 dB(A). Con-
formity assessment procedure according to Annex V.
Equipment category: 25
Technical file (2006/42/EC, 2000/14/EC) at:
Bosch Lawn and Garden Ltd., PT-HG/ENS-PA2,
Stowmarket, Suffolk IP14 1EY, England
Henk Becker
Helmut Heinzelmann
Executive Vice President
Head of Product Certification
Engineering
PT/ECS
Robert Bosch Power Tools GmbH
70538 Stuttgart, GERMANY
Stuttgart, 01.01.2017
Mounting and Operation
Action
Delivery Scope
Battery Charging
Detaching Tool
Attaching Tool
Switching On and Off
Fitting Telescopic handle
Adjusting handle length
Setting for Edge Cutting
Maintenance
Accessories
Cutting Hedges
Before cutting check the hedge for foreign objects e. g. wire
fences.
Application
To maintain control hold the machine properly by the handle.
Holding the machine incorrectly could result in injury.
After use replace the blade transport guard.
Telescopic handle
The telescopic handle can be used with the grass and shrub
shear attachment. Before using the handle with the shrub
shear attachment, the wheels should be detached.
English | 15
Figure
Page
1
224
2
224
3
224
4
225
5
225
6
225
7
226
8
226
9
226
10
227
F 016 L81 340 | (2.11.16)
