5.4.5 Print Position Adjustment

Selection
TRACT.L. V-POS
Tractor Lower Vertical Position
TRACT.L. H-POS
Tractor Lower Horizontal Position
TRACT.U. V-POS
Tractor Upper Vertical Position
TRACT.U. H-POS
Tractor Upper Horizontal Position
MANUAL V-POS.
Manual Vertical Position
MANUAL H-POS.
Manual Horizontal Position
BIN 1 V-POS.
Bin 1 Vertical Position
BIN 1 H-POS.
Bin 1 Horizontal Position
BIN 2 V-POS.
Bin 2 Vertical Position
BIN 2 H-POS.
Bin 2 Horizontal Position
BIN 3 V-POS.
Bin 3 Vertical Position
BIN 3 H-POS.
Bin 3 Horizontal Position
1)
MANUAL for PP 806 and as an Option for PP 803.
2)
ASF Cassetts (BIN 1 to BIN 3) only for PP 806.
5-6
Entry Point = DEFINE MACRO -> PRINT POS.ADJ.
Parameter / Value
TRACT.L.
(Range: -24.0 up to 99.9; Unit:
TRACT.L.
(Range: -9.0 up to 24.0; Unit:
TRAKT.U.
(Range: -24.0 up to 99.9; Unit: 1/6 inch)
TRACT.U.
(Range: -9.0 up to 24.0; Unit: 1/10 inch)
1) MANUAL
(Range: -1.5 up to 24.0; Unit: 1/6 inch)
1) MANUAL
(Range: -9.0 up to 24.0; Unit: 1/10 inch)
2) BIN 1
(Range: -1.5 up to 24.0; Unit: 1/6 inch)
2) BIN 1
(Range: -9.0 up to 24.0; Unit: 1/10 inch)
2) BIN 2
(Range: -1.5 up to 24.0; Unit: 1/6 inch)
2) BIN 2
(Range: -9.0 up to 24.0; Unit: 1/10 inch)
2) BIN 3
(Range: -1.5 up to 24.0; Unit: 1/6 inch)
2) BIN 3
(Range: -9.0 up to 24.0; Unit: 1/10 inch)
Menu Structure
default
V. 0.0
/
1
inch)
6
H. 0.0*
/
1
inch)
10
V. 0.0
H. 0.0*
V. 0.0
H. 0.0*
V. 0.0
H. 0.0*
V. 0.0
H. 0.0*
V. 0.0
H. 0.0*
*
*
*
*
*
*
