BBG-1034-AUD-PRO
BBG-1034-AUD-PRO
3G/HD/SD-SDI Standalone Advanced Audio Processor
with DSP Audio Options Support and Full Embed/De-Embed
Product Manual
Cobalt Digital Inc.
2506 Galen Drive
Champaign, IL 61821
Voice 217.344.1243 • Fax 217.344.1245
www.cobaltdigital.com
BBG-1034-AUDPRO-OM (V1.1)
