SECTION 2
1
2
5
1. Fluid Filter
2. Moisture Separator
3. Receiver Tank
4. Fluid Fill
5. Fluid Fill Sight Glass
6. Starter Box
7. WS Controller
6
Figure 2-1: Overall Component Layout, Air-Cooled Model
10
6
7
8
9
12
8. E-Stop Button
9. Compressor Unit
10. Cooler Fan Motor
11. Cooler
12. Motor
13. Air Inlet Filter
3000-4500 Operator's Manual and Parts List
11
1
3
5
4
13
2
