Sullair 375 User Manual

Portable air compressor
Hide thumbs Also See for 375:
Table of Contents

Advertisement

Quick Links

Portable Air Compressor
375, 375H, 400HH, 425, 425H
SAFETY WARNING
Users are required to read the
entire User Manual before han-
dling or using the product.
USER MANUAL
Tier 4 Final
Caterpillar
WARRANTY NOTICE
Failure to follow the instructions
and procedures in this manual,
or misuse of this equipment, will
void its warranty.
Subject to EAR, ECCN EAR99 and related export control restrictions.
PART NUMBER:
02250223-036 R01
The information in this manual is current as of its
publication date and applies to compressor models
indicated on this cover with serial number:
201605010000
and all subsequent serial numbers.
Publication date: 05/27/2016
Copyright © 2016 Sullair, LLC. All rights reserved.
