Kramer VP-770 User Manual

Presentation switcher/scaler
Hide thumbs Also See for VP-770:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
im Vertrieb von
www.camboard.de
CAMBOARD Electronics
K R A ME R E LE CT R O N IC S L TD .

USER MANUAL

MODEL:
VP-770
Presentation Switcher/Scaler
P/N: 2900-300173 Rev 4
Tel. 07131 911201
Fax 07131 911203
ce-info@camboard.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VP-770 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kramer VP-770

Summary of Contents for Kramer VP-770

  • Page 1: User Manual

    Vertrieb von CAMBOARD Electronics K R A ME R E LE CT R O N IC S L TD . USER MANUAL MODEL: VP-770 Presentation Switcher/Scaler P/N: 2900-300173 Rev 4 www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 2 im Vertrieb von CAMBOARD Electronics www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 3 im Vertrieb von CAMBOARD Electronics www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 4: Table Of Contents

    Controlling via the VP-770 Web Pages Connecting to the VP-770 via RS-232 Connecting the VP-770 via the ETHERNET Port Controlling the VP-770 via the REMOTE Terminal Block Connector Controlling via the Infrared Remote Control Transmitter Port Tunneling Flash Memory Upgrade Technical Specifications 11.1...
  • Page 5 Vertrieb von CAMBOARD Electronics Figures Figure 1: VP-770 Presentation Switcher/Scaler Front Panel Figure 2: VP-770 Presentation Switcher/Scaler Rear Panel Figure 3: 15-pin HD Connector Pinout Figure 4: Connecting the VP-770 Presentation Switcher/Scaler Figure 5: TP PINOUT Figure 6: Microphone Pinout...

  • Page 6: Introduction

    Vertrieb von CAMBOARD Electronics Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront video, audio, presentation, and broadcasting professionals on a daily basis. In recent years, we have redesigned and upgraded most of our...

  • Page 7: Getting Started

    Avoid interference from neighboring electrical appliances that may adversely influence signal quality  Position your Kramer VP-770 away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building.

  • Page 8: Recycling Kramer Products

    Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

  • Page 9: Overview

     Port tunneling, bidirectional RS-232 interface – simple control commands and data can flow in both directions from a controller to the VP-770 via the Ethernet, allowing status requests and control of the destination unit VP-770 - Overview www.camboard.de...
  • Page 10  Automatic detection and selection of the HDMI and DP embedded audio. The VP-770 automatically outputs the signal from the HDMI and DP embedded audio inputs or performs an analog takeover to output the respective analog audio input ...
  • Page 11 Via contact closure remote control switching  Via the Ethernet (optionally via the Web pages) The VP-770 is housed in a 19” 1U rack mountable enclosure, with rack “ears” included, and is fed from a 100-240 VAC universal switching power supply. VP-770 - Overview www.camboard.de...

  • Page 12: Hdcp Compliance

    About the Power Connect™ Feature The VP-770 can power the receiver on the DGKat output when the devices are within 90m (270ft) of each other. The Power Connect™ feature applies as long as the cable can carry power and the distance does not exceed 90m on standard TP cable.

  • Page 13: Figure 1: Vp-770 Presentation Switcher/Scaler Front Panel

    Vertrieb von CAMBOARD Electronics Figure 1: VP-770 Presentation Switcher/Scaler Front Panel Feature Function IR Receiver Accepts IR remote commands IR LED Lights red when the unit accepts IR remote commands INPUT Selector HDMI Press to select the HDMI input (from 1 to 2)

  • Page 14: Figure 2: Vp-770 Presentation Switcher/Scaler Rear Panel

    Vertrieb von CAMBOARD Electronics Figure 2: VP-770 Presentation Switcher/Scaler Rear Panel Feature Function AUDIO IN HDMI 3.5mm Mini Jack Connect to an unbalanced audio source for audio takeover of the HDMI 1 and HDMI 2 embedded audio Unbalanced (see Section 6.3).
  • Page 15 HDMI Connect to an HDMI acceptor Connectors DGKAT RJ-45 Connect to a DGKat receiver (for example, Kramer PT-572+) RS-232 9-pin D-sub Port Connect to the PC or other serial controller ETHERNET Connector Connects to the PC or other Controller through computer networking...

  • Page 16: Installing In A Rack

    Vertrieb von CAMBOARD Electronics Installing in a Rack This section provides instructions for rack mounting the unit. VP-770 - Installing in a Rack www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 17: Connecting The Vp-770

    Alternatively, you can connect the DVI connector on the DVD player to the HDMI connector on the VP-770 via a DVI-HDMI adapter. You can connect the audio signal via the AUDIO IN HDMI 3.5mm mini jack, or use the embedded audio 2.
  • Page 18 8. Connect the HDMI VIDEO OUTPUT connector to an HDMI acceptor (for example, a plasma display). 9. Connect the DGKAT RJ-45 connector to a receiver (for example, the Kramer PT-572+). 10. Connect the SPKR Terminal Block connector to speakers (not shown in Figure 11.

  • Page 19: Figure 4: Connecting The Vp-770 Presentation Switcher/Scaler

    Vertrieb von CAMBOARD Electronics Figure 4: Connecting the VP-770 Presentation Switcher/Scaler VP-770 - Connecting the VP-770 www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 20: Wiring The Tp Line In / Line Out Rj-45 Connectors

    Figure 5: TP PINOUT EIA /TIA 568B Wire Color Orange / White Orange Green / White Blue Blue / White Green Brown / White Brown VP-770 - Connecting the VP-770 www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 21: Microphone Pinout

    This section defines the microphone 3.5mm jack pinout. Figure 6: Microphone Pinout Audio Input Pinout This section defines the audio input 3.5mm jack pinout. Figure 7: Audio Input Pinout VP-770 - Connecting the VP-770 www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 22: The Osd Menu

    Vertrieb von CAMBOARD Electronics The OSD Menu The VP-770 OSD menu lets you set the operation parameters for the:  Main Window Control  PIP Window Control  Entire System Control The nature of the operation setup appears in the OSD title, as shown in the...
  • Page 23 Control). General characteristics which apply to the entire system (for example, setting the volume) are changed without needing to shift control (the title line will state: Entire System Control). VP-770 - The OSD Menu www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 24 Data is saved per window and per input (to a dedicated input + window memory), as applicable The control buttons let you control the VP-770 via the OSD menu. Press the:  MENU (or ) button to enter the menu, exit the menu, and when in the OSD menu, move to the previous level and change menu settings in the OSD screen.

  • Page 25: The Input Menu

    Input Source Select the input source: HDMI1, HDMI2, PC1, PC2, COMP, CV1, CV2 or Note that SDI is not applicable to the VP-770 and appears transparent in the OSD. The commands related to SDI in the OSD menu are therefore grayed out.
  • Page 26 PC 1, PC 2 and DP inputs. Setting the EDID on any one of the HDMI inputs affects that HDMI input immediately (the VP-770 automatically issues a hot- plug) and will affect the other HDMI video source only after a hot-plug occurrence on that input.

  • Page 27: Figure 9: Select The Display Mode

    Make sure that you have control over the window that requires customization (Main Window Control or PiP Window Control). If not, select it via the OSD item in the Miscellaneous menu, see Section 6.8. VP-770 - The OSD Menu www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 28: Figure 10: Changing The Size Of The Window

    3. Select H width (an OSD slide bar appears) and press + to increase the width, or – to decrease the width, see Figure The following example shows how to increase the width of the window VP-770 - The OSD Menu www.camboard.de Tel. 07131 911201 ce-info@camboard.de...

  • Page 29: Figure 11: Increasing The Width

    Use the H Position and V Position items in the OSD to change the position of the window using the + and – buttons on the front panel or remote control transmitter (as illustrated in Figure 13). VP-770 - The OSD Menu www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 30: Figure 13: Positioning The Window

    2. Select Window Customization. The following Window appears: Figure 14: Window Customization 3. To move the picture to the right, select H Position. An OSD slide bar appears: VP-770 - The OSD Menu www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 31: Figure 15: H-Position Slide Bar

    Note that the sequence in which you change the size and position of the window is insignificant, as long as you make sure that the resized image does not go beyond the window boundaries. VP-770 - The OSD Menu www.camboard.de Tel. 07131 911201 ce-info@camboard.de...

  • Page 32: The Audio Menu

    In the Mix mode, the microphone input is mixed with the audio output at a set level. You can also set the Line Mix separately. VP-770 - The OSD Menu www.camboard.de Tel. 07131 911201 ce-info@camboard.de...

  • Page 33: Figure 18: Set The Output Volume Level

    Amplifier This submenu item is specific for the power amplifier, on top of the general volume level Note that SDI is not applicable to the VP-770 and appears Channeling transparent in the OSD. The commands related to SDI in the OSD menu are therefore grayed out.

  • Page 34: The Process Menu

    Select the motion detection sensitivity for filtering of interlaced images. Set a high value for video where there is generally a large amount of motion, or a low value for little motion VP-770 - The OSD Menu www.camboard.de Tel. 07131 911201 ce-info@camboard.de...

  • Page 35: The Picture Menu

    Set the image color (back to its default values) and position per window (centers it correctly on the screen) See Auto Positioning menu item in Section 6.8 Note that Auto Adjust is disabled when in the Freeze state VP-770 - The OSD Menu www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 36: The Enhance Menu

    Block NR – as the level is set higher, the block noise is reduced and the image appears softer Input noise reduction (except for Temporal NR) is enabled for interlaced video processing only and is inactive in the progressive scan. VP-770 - The OSD Menu www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 37: The Scale Menu

    6.8) Deep Color – to Off (the default) for 8bit color depth or to Follow Output for applying deep color automatically on the HDMI/DGKat output if supported by the display VP-770 - The OSD Menu www.camboard.de Tel. 07131 911201 ce-info@camboard.de...
  • Page 38 HDCP compliant, the VP-770 always outputs without HDCP and vice versa. Not that the VP-770 will output a green screen if the output acceptor to which it is connected is not HDCP compliant, in the case that the video on the Main or PiP window is HDCP encrypted.
  • Page 39 By setting the output resolution to Native, the VP-770 is triggered to read the EDID of the main display and change the output resolution value according to the native resolution of the display.

  • Page 40: The Miscellaneous Menu

    Blink Period – to determine the blinking rate Timeout – to 30 seconds before OSD timeout, 60 seconds before OSD timeout or OFF (Off means that that the OSD appears continuously) VP-770 - The OSD Menu www.camboard.de Tel. 07131 911201 ce-info@camboard.de...
  • Page 41 (once restored, the buttons return to their normal function) When using the VP-770 for audio only, we recommend that you turn this feature off Luma Keying – to set the transparency level of the PIP window (see Section 6.8.1)
  • Page 42 When the luma keying feature is On, any change in the setup (either by the user or by resetting due to a setup change) may cause the screen to flicker once. The luma keying will recover automatically after resetting. VP-770 - The OSD Menu www.camboard.de Tel. 07131 911201 ce-info@camboard.de...
  • Page 43 1.0.pdf. The VP-770 intercepts XML files over the Ethernet in the CAP format via the dedicated EAS port from the alert generator server (for example, a FEMA server or a proprietary CAP message generation application) for immediate alert message triggering.

  • Page 44: Figure 24: Xml File Transfer

    The Expiration Date field of the CAP XML file determines when the message will expire. Note that you can remove the message sooner by pressing/clicking any of the buttons on the VP-770 (front panel or remote control buttons, as well as via the Web page or protocol commands).
  • Page 45 CAMBOARD Electronics 1. Set the dedicated EAS Ethernet connection port type and port number through which the VP-770 will be listening, as a client, to intercept alerts. By default, the dedicated EAS port settings are TCP, 5005. To change these setting see the “Emergency Alert Configuration”...

  • Page 46: The Display Modes

    OSD menu. 7.1.1 Activating the Single window Mode Set the VP-770 to the single window display mode in any of the following ways:  Press and hold (for 3 seconds) the illuminated front panel PIP button until the button no longer illuminates ...
  • Page 47 If the HDMI signal is HDCP protected, it can appear on HDMI and DGKat outputs that are connected to supported HDCP compliant displays. However, it cannot appear on a display that is not HDCP compliant and the VP-770 will not output a picture on the VGA output. VP-770 - The Display Modes www.camboard.de...
  • Page 48 PiP window parameters via the other menu items. To return to Main Window control, repeat the procedure above but select Main Window in the Window Control submenu. VP-770 - The Display Modes www.camboard.de Tel. 07131 911201 ce-info@camboard.de...

  • Page 49: Figure 26: Cv1 Superimposed Over Dp

    7.2.3 Selecting the PIP Source To select a PiP source you have to set the VP-770 to any of the PiP display mode configurations and then select the desired input. 7.2.3.1 Selecting the PiP Source via the Front Panel Buttons Press and hold the PIP front panel button while pressing the input button of the required PiP source.
  • Page 50 8. Select Input Source and press ENTER. 9. Choose the input for the PiP window. 10. Press the MENU a few times until you exit the OSD menu (changes are saved upon exit). VP-770 - The Display Modes www.camboard.de Tel. 07131 911201 ce-info@camboard.de...

  • Page 51: Controlling The Vp-770

    Section 8.7) Controlling via the Front Panel Buttons The VP-770 includes the following front panel buttons:  Input selector buttons for selecting the required input: HDMI (1 and 2), PC (1 and 2), COMP, CV (1 and 2) and DP (see Section 8.1.1)

  • Page 52: Controlling Via The Osd Menu

    Note that if the Protocol is set to Legacy (via the Miscellaneous menu, Section 6.8), the Web pages may not function properly. Make sure that your PC is connected via a network to the VP-770 and do the following: 1. Open your Internet browser.

  • Page 53: Connecting To The Vp-770 Via Rs-232

    To connect to the VP-770 via RS-232, connect the RS-232 9-pin D-sub rear panel port on the VP-770 unit via a 9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3, and pin 5 to pin 5 need to be connected) to the RS-232 9-pin D-sub port on your PC.

  • Page 54: Figure 28: Local Area Connection Properties Window

    Connecting the ETHERNET Port via a Network Hub (Straight- Through Cable) You can connect the Ethernet port of the VP-770 to the Ethernet port on a network hub or network router, via a straight-through cable with RJ-45 connectors. VP-770 - Controlling the VP-770 www.camboard.de...

  • Page 55: Controlling The Vp-770 Via The Remote Terminal Block Connector

    Vertrieb von CAMBOARD Electronics 8.5.3 Ethernet Port Configuration and Control Use the Kramer K-UPLOAD software to configure and control the VP-770 via the Ethernet. The latest version of K-UPLOAD and installation instructions can be downloaded from the Kramer Web site at http://www.kramerelectronics.com/support/product_downloads.asp...

  • Page 56: Figure 31: Connecting The Pip Contact Closure Remote Control Pins

    PIP pin to the G pin and, within 3 seconds, the 5 pin to the G pin, as illustrated in Figure Figure 31: Connecting the PIP Contact Closure Remote Control PINs VP-770 - Controlling the VP-770 www.camboard.de Tel. 07131 911201 ce-info@camboard.de...

  • Page 57: Controlling Via The Infrared Remote Control Transmitter

    Controlling via the Infrared Remote Control Transmitter This IR remote control transmitter is compatible with various Kramer machines, therefore not all its buttons are applicable to the VP-770. The table below defines only the buttons that are relevant to the VP-770;...
  • Page 58 This distance can be extended to up to 60 meters when used with three extension cables (Model: C-A35M/A35F-50). Before using the external IR receiver, be sure to arrange for your Kramer dealer to insert the internal IR connection cable (P/N: 505-70434010-S) with the 3.5mm connector that fits into the REMOTE IR opening on the rear panel.

  • Page 59: Port Tunneling

    CAMBOARD Electronics Port Tunneling The port tunneling feature lets you send and receive simple RS-232 signals between a controller and a serial device via the VP-770 which is connected to the Ethernet and outputs via TP cable. The example, illustrated in...
  • Page 60 Section 12.4). By default, the settings are 9600,8,N,1 3. Make sure that the VP-770 is connected to Ethernet. The VP-770 is now ready to tunnel RS-232 signals via Ethernet port tunneling. VP-770 - Port Tunneling www.camboard.de Tel. 07131 911201 ce-info@camboard.de...

  • Page 61: Flash Memory Upgrade

    Vertrieb von CAMBOARD Electronics Flash Memory Upgrade You can upgrade the VP-770 via the Kramer K-UPLOAD software. Two types of upgrade files are available for upgrade: video core and audio/graphics (*.fct) and peripherals (*.kfw). The latest firmware version, the Flash Memory Upgrade user guide, as...

  • Page 62: Technical Specifications

    Power cord, rack “ears”, IR remote control ACCESSORIES: Specifications are subject to change without notice For the most updated resolution list, go to our Web site at http://www.kramerelectronics.com VP-770 - Technical Specifications www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 63: 11.1 Default Communication Parameters

    525_P60 1280x1024_75 1600x900_60 640x480_75 1024x768_60 720_P50 1280x1024_85 1600x1200_60 640x480_85 1024x768_70 720_P60 1360x768_60 1680x1050_60 800x600_56 1024x768_75 1280x800_60 1366x768_60 1920x1200_60RB 800x600_60 1024x768_85 1280x960_85 1440x900_60 1080_P50 800x600_72 1152x864_75 1280x768_60 1400x1050_60 1080_P60 VP-770 - Technical Specifications www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 64 1080_P30 800x600_60 1280x800_60 1400x1050_75 720_P25 1080_P50 800x600_72 1280x960_85 1600x900_60 720_P30 1080_P60 800x600_75 1280x768_60 1600x1200_60 720_P50 2K50 800x600_85 1280x1024_60 1680x1050_60 720_P60 2K60 848x480_60 1280x1024_75 1920x1200_60RB 1080_I50 640X480_60 1024x768_60 1280x1024_85 VP-770 - Technical Specifications www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 65: 11.3 Output Resolutions

    576i50 1080p30 800x600@60 1366x768@60 576p50 1080p50 800x600@75 1400x1050@60 720p50 1080p59.94 1024x768@60 1600x900@60 720p59.94 1080p60 1024x768@75 1600x1200@60 720p60 2K50 1280x768@60 1680x1050@60 1080p23.976 2K60 1280x800@60 1920x1200@60 1080p24 1280x1024@60 480i60 1080p25 VP-770 - Technical Specifications www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 66: The Vp-770 Rs-232 Communication Protocol

    ® software (for example, the Windows HyperTerminal Application). 12.1 Using the Communication Protocol There are three different methods to control the VP-770 via the RS-232 or the Ethernet:  Protocol commands (via protocol 3000 or Legacy Protocol) mimicking the OSD, see Section 12.2...
  • Page 67 Send: “#Y 0,141,-,1<CR>” Reply: “~01@Y 0,141,-,1 OK” For example, in order to increase zoom on the main windows Send: “#Y 0,650,+,0<CR>” Reply: “~01@Y 0,650,+,0 OK” VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 68 6.1). When navigating in the OSD MENU you will be able to see the Film Mode valid parameters. Note that SDI is not applicable to the VP-770 and appears transparent in the OSD. The commands related to SDI in the protocol commands VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de...
  • Page 69 The color depth bit is the MSB of PM.EDID_SEL (which represents the resolution). For example, when selecting 1600x900@60 at: 8bpp, PM.EDID_SEL = 86h=134 dec 12bpp, PM.EDID_SEL = 6h=6 dec VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de...
  • Page 70 Power Level 4 Group A None 0 (read only) Channeling Activate CH1 Activate CH2 Bypass Group B None 0 (read only) Activate CH1 Activate CH2 Bypass VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 71 Gamma 1.6 Gamma 2.0 Gamma 2.4 Gamma 2.8 Dither Mode0: Disable error diffusion Mode1: In-frame 8:6 conversion Mode2: Intra-frame 8:6 conversion Mode3: In-frame 10:8 conversion VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 72 MENU screen, 800x600@75 follow OSD 1024x768@50 instructions 1024x768@60 1024x768@75 1280x768@50 1280x768@60 1280x800@60 1280x1024@50 1280x1024@60 1280x1024@75 1360x768p60 1366x768@50 1366x768@60 1400x1050@50 1400x1050@60 1600x900@60 1600x1200@50 1600x1200@60 1680x1050@60 1920x1200@60 480i60 VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 73 - Input, Output PAL60 video formats & FW version. N443 NTSC_4 In the protocol – SECAM Get command returns the Input video format only PALNC NTSC_8 VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 74 1080p24 1080p25 2K50 2K60 640X480@60 640x480@72 640x480@75 848x480@60 640x480@85 800x600@56 800x600@60 800x600@72 800x600@75 800x600@85 1024x768@60 1360x768@60 1280x768@60 1024x768@70 1024x768@75 1280x800@60 1024x768@85 1400x1050@60 1400x1050@75 1440x900@60 1152x864@75 VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 75 Keying the PiP window Alert System Pause Freeze Blank In the PiP Mode, Mute applies to main window only Follow OSD Disable Outputs instructions. Self-clearing. VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 76: Protocol Table: Mimicking Remote And Front Panel Buttons

    CH1_CV1 CH2_VGA1 DUMMY CH1_CV2 CH2_VGA2 12.4 The Protocol 3000 Common Operation Commands Operation commands Command Syntax Response Lock front panel LOCK-FP LOCK-MODE LOCK-FP LOCK-MODE RESULT VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 77 “0” to notify that the alert went off either by timeout or by keystroke SET dedicated port PTNL-CFG PORTTYPE, PTNL-CFG CFG PORTTYPE, tunneling settings PORTNUM PORTNUM RESULT GET dedicated port PTNL-CFG? PTNL-CFG PORTTYPE, tunneling settings PORTNUM VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 78 "0" or "off" for single window. "1" or "on" to for dual window. Identification commands Command Syntax Response Protocol ~OK CRLF Handshaking Read device model MODEL? MODEL MACHINE_MODEL VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 79 0 (factory default) – Don't use DHCP (Use IP set by factory or IP set command). 1 – Try to use DHCP, if unavailable use IP as above. 2– Try to use DHCP, if unavailable use AUTO-IP as described here: http://support.microsoft.com/kb/q307287/ . VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de...
  • Page 80 Step 1: LDMFS SIZE audio/graphic Response 1: READY or LDMFS SIZE ERR### memory file. Step 2: If ready was received, send FIRMWARE_DATA Response 2: LDMFS SIZE RESULT VP-770 - The VP-770 RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 81 im Vertrieb von CAMBOARD Electronics www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 82 Vertrieb von CAMBOARD Electronics For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com...
